Design on Ultrahigh Vacuum System with Titanium Pump

Abstract:

In order to meet the further requirements that study diamond-like carbon (DLC) films as rigid protective coating, a three-stage ultrahigh vacuum system composed of rotary vane pump and diffusion pump in parallel with TSP ( titanium sublimation pump) was designed mainly for getting limiting vacuum of 1.0×10^-6Pa within 30 minutes in the vacuum chamber of about 0.23m³. The chamber is a horizontal cylinder supported by a saddle-shaped bracket and it has been proved to satisfy the requirements of strength and stiffness, it can be easy to get ultrahigh vacuum by TSP. Initiation pressure of the TSP was set to 10^-3Pa vacuum after optimization analysis and the diffusion pump simultaneously was closed for the proper use. The system can be used as deposition equipment with the assistance of high and low vacuum measuring instruments and other accessories.

• Periodical: Advanced Materials Research (Volume 702)
• Pages: 286-290
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.702.286
• Online since: May 2013
• Authors: Jin Hua Zheng, Yun Feng Chao, Chong Zhang, Cong Hui Li
• Keywords: Selection, Structural Design, Vacuum System, Validation

References

[1] J.Zheng, Y.Chen: A Study on Interface Strength of a-Si:H-DLC Film, Advanced Materials Research Vol. 179-180 (2011), pp.775-780.

DOI: 10.4028/www.scientific.net/amr.179-180.775

[2] Chong Zhang, Jinhua Zheng: Design on High Vacuum System with Molecular Pump, Applied Mechanics and Materials Vol. 220-223 (2012), pp.459-462.

[3] D. Da: Vacuum Design Manual (National Defence Industry Press, BeiJing 1991).

[4] X.Liu,C.Han: Buckling Safety Factor of Steel thin-walled External Pressure Vessels, Petrochemical equipment and technology Vol. 6 (2009) , pp.16-18.

[5] C.Pan: Design on High Vacuum System of High Vacuum Coating Equipment, Progress Report on China Nuclear Science & Technology Vol. 1 (2009) , pp.182-190.
