An Experimental Study on the Clearance Design of Fine Blanking Tool for High-Strength Steel Special Parts with Various Inner Corner Shapes

Abstract:

The clearance between the punch and die of a fine blanking tool is an important design factor that affects the sheared surface of a product. In a fine blanking process, the clearance is typically assigned a 0.5% material thickness. If the clearance is too big, a fractured surface would occur in the product while if it is too small, bulging would occur.In this study, a setting for optimum clearance was proposed for inner corner shapes by checking shear characteristics and bulging effects according to various clearances. After designing a special part with various corner shapes possessing SPFH590 (thickness: 4 mm), a high-strength steel material, a fine blanking tool was constructed and fine blanking experiments were conducted. The result could be usefully applied in fine blanking processes for high-strength steel automobile parts with corner shapes in the future.

You might also be interested in these eBooks

Mechatronics and Intelligent Materials III

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 706-708)

Pages:

426-430

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.706-708.426

Citation:

Cite this paper

Online since:

June 2013

Authors:

Jong Deok Kim, Young Moo Heo, Ho Keun Kang, Si Tae Won

Keywords:

Bulging, Clearance, Fine Blanking Tool, SPFH590

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] W. Blatter, in: Introduction into the technology fine blanking tools, Incheon, KAITECH (1991).

Google Scholar

[2] Taylan Altan, in: Metal Forming Handbook, Shuler GmbH, chapter 4, Berlin Heidelberg NewYork, Springer-Verlag (1998).

Google Scholar

[3] K. Lange, F. Birzer, P. Hoefel, A. Muhoty, H. Singer, in: Cold forming and Fineblanking - A handbook on cold processing, material properties, component design, EdelstahlwerkeBuderus AG, Feintool AG Lyss, HoeschHohenlimburg GmbH, KaltwaltzwerkBrockhaus GmbH (1997).

Google Scholar

[4] Jong-Deok Kim, Heung-Kyu Kim, Young-Moo Heo, Sung-Ho Chang, A study on the effect of V-ring position on the die roll height in fine blanking for special automobile seat recliner gear, Advanced Materials Research, Vols. 383-390, 2012, pp.7122-7127.

DOI: 10.4028/www.scientific.net/amr.383-390.7122

Google Scholar

[5] Franz Birzer, in: Forming and fineblanking / cost-effective manufacture of accurate sheetmetal parts, Landesberg/Lech, verlagmoderneIndustrie (1997).

Google Scholar
