Experiment Study on Dynamic Effects of Ice Shedding on Overhead Transmission Line

Abstract:

The vibration caused by ice shedding from overhead transmission line will lead to a great damage to transmission line in ice disaster areas, so it is of great significance for line design to research the vibration characters caused by ice shedding. In order to research the characters of tensile force in ice shedding conductor, the ice shedding phenomenon is simulated in laboratory by a single conductor between isolated span. The result shows that: the ice-shedding response amplitude will increase as the increase of ice thickness, the decrease of the sag-span ratio or the increase the shedding ice quantity; the max dynamic tension caused by part of ice shedding from conductor may larger than the whole ice-shedding.

• Periodical: Advanced Materials Research (Volume 710)
• Pages: 306-310
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.710.306
• Online since: June 2013
• Authors: Wen Gang Yang, Shi Bin Su, Zhang Qi Wang
• Keywords: Ice Shedding from Line, Transmission Line, Vibration of Ice Shedding

References

[1] Jingbo Yang, Zheng Li, Fengli Yang,al. Analysis of Features of Covered Ice and Collapsed Tower of Transmission Line Snow and Ice Attacked in 2008[J].Advances of power System & Hydroelectric Engineering,2008,24(4):4-8.(in chinese)

[2] G.McClure, M.Lapointe. Modeling the structural dynamic response of overhead transmission line[J]. Computers & Structures,2003,81:825-834.

DOI: 10.1016/s0045-7949(02)00472-8

[3] Fekr.M.R, McClure.G. Numerical modeling of the dynamic response of ice-shedding on electrical transmission line [J].Atmospheric Research,1998,46:1-11.

DOI: 10.1016/s0169-8095(97)00046-x

[4] Kalman.T, M. Farzaneh a, G. McClure. Numerical analysis of the dynamic effects of shock-load-induced ice shedding on overhead ground wires[J].Computers & Structures,2007, 85:375-384.

DOI: 10.1016/j.compstruc.2006.11.026

[5] L.E. Kollár, Masoud Farzaneh. Vibration of Bundled Conductors Following Ice Shedding[J]. Transactions on Power Delivery2008,23(2):1097-1104.

DOI: 10.1109/tpwrd.2007.915876

[6] Lei Hou, Liming Wang, Puxuan Zhu. Dynamic Behavior Computation of Ice Shedding of UHV Overhead Transmission Line[J].Proceedings of the CSEE,2008,28(6):1-6. (in chinese)

[7] Guohui Shen, Guanghui yuan,Bingnan Sun, al. Dynamic Impact Effects on Tower-line System due to Ice-shedding[J].Engineering Mechanics, 2010,27(5):210-217. (in chinese)

[8] Morgan.V.T, Swift.D. Jump height of overhead-line conductors after the sudden release of ice loads [J].Proceedings of IEE,1964,111(10): 1736―1746.

DOI: 10.1049/piee.1964.0285

[9] Jamaleddine.A. Simulation of ice-shedding on electrical transmission line using ADINA[J ]. Computers & Structures ,1993 ,47 (4/ 5) :523-536.

DOI: 10.1016/0045-7949(93)90339-f

[10] Xiaobo Meng, Liming Wang, Lei Hou,et al. Dynamic characteristic of ice-shedding on UHV overhead transmission line[J].Cold Regions Science and Technology,2011,66:44-52.

DOI: 10.1016/j.coldregions.2011.01.005

[11] Zhengchun Xia. Research on Galloping and Ice-shedding of Ultra High-voltage Transmission Conductors[D].Wu Han: Huazhong University of Science & Technology,2008:85-86. (in chinese)

[12] Bin Chen, Deku Zheng. Analysis on the Question of Ice Coating Damage to Overhead Transmission Line[J]. Jilin Electric Power, 2005,181:25-27. (in chinese)
