Designing Piezoelectric Harvesting Unit from Road Vibration

Abstract:

To open up a new way of green energy, the piezoelectric harvesting technology from road vibration is proposed. Research status at home and abroad is reviewed, some existed problems are pointed out. With the software of ANSYS, the arrayed space between piezoelectric vibrators and the material and thickness of substrate are chosen in the light of higher harvesting energy and better coupling properties. From the simulation results, can a unit of 280*280*20mm be determined. When it is embedded under 40mm asphalt concrete pavement, 1.785MW electric power can be harvested from each traffic lane and per kilometer. This shows that application of the piezoelectric harvesting unit has very nice optimistic prospects.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 1368-1371
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.1368
• Online since: June 2013
• Authors: Chun Hua Sun, Guang Qing Shang, Yong Kang Zhang, Jian Hong Du
• Keywords: Arrayed, Piezoelectric Harvesting Unit, PZT, Road Vibration

References

[1] Y.M. Liu. Active energy harvesting. University Park: the Pennsylvania State University, (2006)

[2] Comprehensive planning division of Ministry of Transport of China. 2011 statistical bulletin of highway and waterway transportation development. (2012)

[3] Information on http://www.innowattech.co.il/index.aspx

[4] B. G. Cao, Z. H. Gao, Z. P. Song, et al. Method and system of highway harvesting energy from piezoelectric vibration: China, Patent 1633009A(2005)

[5] R.B. Huang, Y.L. Niu, H.D. Zhao, et al. Technical approach and research prospect of piezoelectric energy harvest from highway. China Journal of Highway and Transport. Vol.25(2012), pp.1-8.

[6] H.D. Zhao, Y.H. Liang, J.M. Ling. Study on harvesting energy from pavement based on piezoelectric effects. Journal of Shanghai Jiaotong University. Vol.45(Sup. , 2012), pp.62-66

[7] Zhao H D, Yu J, Ling J. Finite element analysis of Cymbal piezoelectric transducers for harvesting energy from asphalt pavement. Journal of the Japan Ceramic Society. Vol.118(2010), pp.909-915

DOI: 10.2109/jcersj2.118.909

[8] C.H. Sun, Y.Y. Tao, H.B. Wang, et al. Piezoelectric Effect of Cymbal Transducer under Action of Alternating Force. Modern manufacturing engineering, Vol.10(2010), pp.91-94

[9] C.H. Sun, X.C. Zhu, G.Q. Shang, et al. Modeling for Piezoelectric Stacks in Series and Parallel. 3th International conference on intelligent system design and engineering applications, 2013 Hongkong: 954-957

DOI: 10.1109/isdea.2012.228
