The Testing and Research of a New Large Bag Filter with the Diaphragm Valve

Abstract:

The diaphragm valve is the key component of the deashing device in a pulse bag filter. It affects the investment cost, operation cost and the floor area, as well as the wide application of the dust removers on jetting performance directly. The development of a low pressure valve with a diameter of 100 was optimized by orthogonal test. The large-sized low-pressure diaphragm valve with the jetting and technical economic performance has been widespread used in market, it was better than small-sized one by parameter comparison between another similar one, the valve body resistance is decreased with the rise of diameter.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 1386-1390
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.1386
• Online since: June 2013
• Authors: Lin Liu, Yuan Peng, Kuang Cheng
• Keywords: Bag Filter, Diaphragm Valve, Jetting Performance, Large-Sized

References

[1] Zhang Dianyin, Wang Chun, and Yu Feilu: Dust bag technology [M]. Beijing Metallurgical Industry Press (2008)

[2] Peng Jingsong: The study about powerful of cleaning diamond-shaped flat bag filter [D]. Wuhan Safety and Environmental Protection Research Institute of the Ministry of Metallurgical Industry (1998), P. 4-6.

[3] Chen Zhiwei: Research on Large Low-Pressure Pulse Valve [D]. Wuhan University of Science and Technology (2002), P. 44.

[4] Yang Fumo: Experimental Study on Evaluation Methods and Means of Pulse Jet Bag Filter Cleaning Ability [D]. Wuhan Safety and Environmental Protection Research Institute of the Ministry of Metallurgical Industry (1992), P. 4-6.

[5] Li Xinghua: Research on Pulse Valve Performance Testing Device [D].Wuhan safety and environmental protection Research Institute (2002), P.14
