Thermo Physical Properties of Copper/Diamond Composites Fabricated by Spark Plasma Sintering

Abstract:

In modern electronic devices overheating has become a critical issue due to high power density and improved performance. In order to overcome this critical issue, the demands for materials having high thermal conductivity with low and tailorable coefficient of thermal expansions are required. This demand can be fulfilled by synthesizing copper/diamond composites, which show excellent thermo-physical properties, compatible with semiconductors and can be used in heat sink and thermal management applications. Copper/Diamond composites were fabricated by Spark Plasma Sintering Method (SPS) by electrolessly copper coated diamond particles pre coated with 1wt% Chromium. The prepared composites were investigated for various properties like thermal conductivity, thermal expansion and characterized by Scanning Electron Microscopy (S.E.M) and X-ray diffraction (X.R.D) analyses. The effect of process parameters were also taken into account. Thermal conductivity of copper/diamond composites fabricated by SPS at 1100°C under pressure of 40MPa, obtained in this case was 400 W/m•K , which is quite higher than those heat sink materials being already in use.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 208-212
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.208
• Online since: June 2013
• Authors: Abdul Rehman Niazi, Shu Kui Li, Ying Chun Wang, Zhi Yu Hu, Usman Zahid
• Keywords: Copper Diamond Composites, Heat Sink Materials, Spark Plasma Sintering (SPS), Thermal Conductivity (TC)

References

[1] Łukas Ciupiński, D. Siemiaszko, Marcin Rosiński, Andrzej Michalski, Krzysztof J. Kurzydłowski. (2009). Heat sink Materials processing by Pulse plasma Sintering. Advanced Materials Research, 59, 120-124

[2] C. Zweben. (2005). Revolutionary New Thermal Management Materials. Electronics Cooling, Vol.11, No.2

[3] C. Zweben. (2007). Advances in high-performance thermal management materials: a review. [J]. Adv. Mater. 39 (1) 3-10

[4] Ke Chu, Zhaofang Liu, Chengchang Jia, Hui Chen, Xuebing Liang, Wenjia Gao,Wenhuai Tian, Hong Guo. (2010) Thermal conductivity of SPS consolidated Cu/diamond composites with Cr-coated diamond particles. Journal of Alloys and Compounds 490, 453–458

DOI: 10.1016/j.jallcom.2009.10.040

[5] K. Yoshida and H. Morigami. (2004). Thermal properties of diamond copper composite material. Microelectron. Reliab. 44(2), 303 – 308.

DOI: 10.1016/s0026-2714(03)00215-4

[6] S.V. Kidalov, F.M. Shakhov, AYa. Vul. (2008). Thermal conductivity of sintered nanodiamonds and microdiamonds. Diamond Relat. Mater. 17, 844-847

DOI: 10.1016/j.diamond.2008.01.091

[7] T. Schubert, B. Trindade, T. Weisg¨arber, B. Kieback.  (2008). Interfacial design of Cu-based composites prepared by powder metallurgy for heat sink applications. Mater. Sci. Eng.A475, 39-44.

DOI: 10.1016/j.msea.2006.12.146

[8] M. Rosin ski, L. Ciupinski, J. Grzonka, A. Michalski, K.J. Kurzydlowski.(2012). Synthesis and characterization of the diamond/copper composites produced by the pulse plasma sintering (PPS) method. [J] Diamond and Related Materials. Vol. (27-28), 29-35

DOI: 10.1016/j.diamond.2012.05.008

[9] T. Weißg¨arber, G. Lefranc, J. Schulz-Harder, H. Meyer, O. Stocker (Eds.), (2003). Advances in Powder Metallurgy & Particulate Materials, part 6, Metal Powder Industries Federation, Princeton, NJ, p.33–40

[10] SHAO W.Z., IVANOV V.V, ZHEN L. et al. A study on graphitization of

[11] Tavangar R, Molina JM, Weber L. (2007). Assessing predictive schemes for thermal conductivity against diamond-reinforced silver matrix composites at intermediate phase contrast. Scripta Mater; 56,357–360

DOI: 10.1016/j.scriptamat.2006.11.008

[12] Weber L, Tavangar R. (2009). Diamond-based metal matrix composites for thermal management made by liquid metal infiltration—potential and limits. Mater Sci. Forum; 59,111–115

DOI: 10.4028/www.scientific.net/amr.59.111

[13] Shen W, Shaoa W, Wanga Q, Maa M. (2010). Thermal conductivity and thermal expansion coefficient of diamond/5 wt%Si–Cu composite by vacuum hot pressing. Fusion Eng Design; 85, 22, 37–40.

DOI: 10.1016/j.fusengdes.2010.08.043

[14] FOROUZANMELU N, KARIMZADEH F, ENAYATI M H. (2009). Study on solid-state reactions of nanocrystalline TiAl synthesized by mechanical alloying [J]. Journal of Alloys and Compounds, 471(1/2), 93-97.

DOI: 10.1016/j.jallcom.2008.03.121

[15] Lixia Cheng, Zhipeng Xie, Guanwei Liu, Wei Liu, Weijiang Xue. (2012). Densification and mechanical properties of TiC by SPS-effects of holding time, sintering temperature and pressure condition. [J] The European Ceramic Society 32, 3399–3406.

DOI: 10.1016/j.jeurceramsoc.2012.04.017
