Measurement Investigation of Complex Eddy Viscosity Model in Non-Equilibrium Wavy Wall Turbulence with TRPIV

Abstract:

The spatial flow fields of turbulent boundary layer over a wavy wall were measured by TRPIV at three different Reynolds numbers in a water channel, the mean streamwise and wall-normal velocities near the wall were calculated from the time series of instantaneous spatial 2D-2C flow fields of turbulent boundary layer, and the periodic distributions of the streamwise and wall-normal velocity in streamwise direction influenced by the wavy wall were found. The spatial distributions of Reynolds stress and mean velocity strain rate were obtained by ensemble average. Using the spatial cross-correlation technique, the spatial phase relationship in streamwise direction between mean velocity strain rate and Reynolds stress was investigated. It is found that there exist spatial phase differences between Reynolds stress components and mean velocity strain rate components, the phase differences increase gradually after decrease gradually from zero away from the wavy wall in wall-normal direction and reach a minimum at 0.4~0.5 times the wavelength of wavy wall, and in a certain range the effect of the Reynolds number on the phase differences is very small. The reasonability of the complex eddy viscosity model is confirmed by these experimental evidences in order to forecast non-equilibrium turbulence accurately.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 1657-1662
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.1657
• Online since: July 2013
• Authors: An Tong Zhang, Nan Jiang
• Keywords: Complex Eddy Viscosity Model, Mean Velocity Strain Rate, Non-Equilibrium Turbulence, Reynolds Stress, Wavy Wall

References

[1] G.L. Brown, A.S.W. Thomas. Large structure in a turbulent boundary layer [J]. Physics of Fluids, 1977,20(10):S243-S252.

DOI: 10.1063/1.861737

[2] R.E. Falco. Coherent motions in the outer region of turbulent boundary layers. Physics of Fluids, 1977,20(10):S124-S132.

DOI: 10.1063/1.861721

[3] R.A. Antonia, D.K. Bisset, L.W. Browne. Effect of Reynolds number on the topology of the organized motion in a turbulent boundary layer [J]. J .Fluid, April 1990, 213:267-286.

DOI: 10.1017/s0022112090002324

[4] W.P. Li, X.Q. Wang, H. Xie, Phase delay of the Reynolds stress and wall pressure fluctuation in wall shear flows. J. Huazhong Univ. of Sci. & Tech. (Nature Science Edition), 2007, 35(4):122~125(in Chinese).

[5] X.J. Wang, J.S. Luo, H. Zhou. On the eddy viscosity model of periodic turbulent shear flows [J]. Acta Mechanics Sinica. 2003, 19(5):470-475.

DOI: 10.1007/bf02484581

[6] J.S. Luo, X.J. Wang, The study of turbulent properties in stable flexuous blow-suck boundary channel flow, Chinese Journal of Theoretical and Applied Mechanics, 2005，37(6): 673~681(in Chinese).

[7] A.D. Guo, N. Jiang, Y.X. Jia, Measurement of phase difference for eddy viscosity model equation of turbulence, Journal of Experiments in Fluid Mechanics, 2011,25(4):1~8(in Chinese).

[8] Y.X. Jia, Z.Q. Tang, N. Jiang. Experimental investigation of Reynolds stress complex eddy viscosity model for coherent structure dynamics [J]. SCIENCE CHINA Physics, Mechanics & Astronomy, 54(7):1319-1327(in Chinese).

DOI: 10.1007/s11433-011-4370-5

[9] I. Hadzic, K. Hanjalic, D. Laurence. Modeling the response of turbulence subjected to cyclic irrotational strain [J]. Phys. Fluids, 2001,13 (6):1740-1747.

DOI: 10.1063/1.1366677

[10] O. Uzol, Y.C. Chow, J. Katz, et al. Experimental study of the structure of a rotor wake in a complex turbo machinery flow[R]. Proceedings of ASME Fluids Engineering Division Summer Meeting Honolulu .Hawaii: July 6-10,2003.

[11] A.J. Revell, S. Benhamadouche, T. Craft, et al. A stress-strain lag eddy viscosity model for unsteady mean flow[J]. Int. J. Heat Fluid Flow, 2006,27:821-830.

DOI: 10.1016/j.ijheatfluidflow.2006.03.027

[12] P. Cherukat, Y. Na, T.J. Hanratty. Direct numerical simulation of a fully developed turbulent flow over a wavy wall [J].Theoretical and computational fluid dynamics, 1998, 11(2):109-134.

DOI: 10.1007/s001620050083

[13] J.D. Hudson, L. Dykhno, T.J. Hanatty. Turbulence production in flow over a wavy wall [J]. Exp Fluids, 1996,20:257-265.

DOI: 10.1007/bf00192670

[14] S. Nakagawa, Y. Na, T.J. Hanratty. Influence of a wavy boundary on turbulence [J]. Experiments in Fluids, 2003,35:422.

DOI: 10.1007/s00348-003-0681-2
