Comparison of Permanent Magnet Linear Synchronous Motor Characteristics Fed by SPWM Inverter and Sinusoid Voltage Source

Abstract:

Permanent Magnet Linear Synchronous Motor (PMLSM) characteristics are deteriorated seriously by amount of time and space harmonics, which are arisen respectively from the inverter comprised array switches, the motor teeth-slots and distributed windings. The paper presents field-circuit coupled adaptive time-stepping finite element method to comparison research on PMLSM characteristics fed by SPWM voltage inverter and sinusoid supply. The co-simulation is used with the status space functions and time-step finite element functions. The simulation results of PMLSM fed by SPWM voltage source inverter and S-VS were compared and analyzed.

• Periodical: Advanced Materials Research (Volume 722)
• Pages: 176-179
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.722.176
• Online since: July 2013
• Authors: An Feng Xu, Qing Hu, Cai Xia Gao
• Keywords: Characteristic, Field-Circuit Coupled Method, Permanent Magnet Linear Synchronous Motor, Sinusoid Voltage Source (S-VS), Sinusoidal Pulse Width Modulation Voltage Inverter (SPWM-VI)

References

[1] Wang Xudong, Yuan Shiying, Jiao Liucheng et al. 3-D analysis of electromagnetic field and performance in a permanent magnet linear synchronous motor. IEMDC 2001, IEEE International, 2001, Cambridge, MA, Boston, USA. 445-447.

DOI: 10.1109/iemdc.2001.939433

[2] Sana da, M.; Morimoto, S.; Takeda, Y.,Interior permanent magnet linear synchronous motor for high-performance drives, IEEE Transactions on Industry Applications, Volume 33, Issue 4, July-Aug. 1997, 966 – 972.

DOI: 10.1109/28.605738

[3] Sang-Yong Jung; Jang-Sung Chun; Hyun-Kyo Jung, Performance evaluation of slotless permanent magnet linear synchronous motor energized by partially excited primary current, IEEE Transactions on Magnetics, Volume 37, Issue 5, Part 1, Sept. 2001, 3757 - 3761.

DOI: 10.1109/20.952707

[4] Sang-Yeop Kwak, Jae-Kwang Kim, Hyun-Kyo Jung. Characteristic Analysis of Multilayer-Buried Magnet Synchronous Motor Using Fixed Permeability Method, IEEE Transaction on Energy Conversion, Vol.20, No.3, September 2005, 549-555

DOI: 10.1109/tec.2005.847973

[5] Gyu-Hong Kang, Jin Hur, Byoung-Kuk, et al. Force Characteristic Analysis of PMLSMs for Magnetic Levitation Stage Based on 3-Dimensional Equivalent Magnetic Circuit Network, IAS 2004, 2099-2104

DOI: 10.1109/ias.2004.1348756

[6] Jung, In-Soung; Hyun, Dong-Seok. Dynamic characteristics of PM linear synchronous motor driven by PWM inverter by finite element analysis, IEEE Transactions on Magnetics, v 35, n 5 pt 2, Sep, 1999, 3697-3699.

DOI: 10.1109/20.800635

[7] Kwon, Byung Il ; Woo, Kyung Il; Kim, Duck Jin; Park, Seung Chan. Finite element analysis for dynamic characteristics of an inverter-fed PMLSM by a new moving mesh technique, IEEE Transactions on Magnetics, v 36, n 4 I, Jul, 2000, 1574-1577

DOI: 10.1109/20.877740
