Current Limiting Reactor's Reactance Value Selection Based on Short-Circuit Transient Analysis

Abstract:

Current limiting reactor can increase systems short circuit impedance so as to limit short circuit current. Current limiting reactor is directly involved in whole short circuit process when a short circuit fault occurs in a power system, which makes short-circuit current change more complex. Short circuit current level is affected by current limiting reactors parameters; a current limiting reactor with proper impedance value can maintain short-circuit current at an acceptable range. A short circuit transient process of a distributing network with current limiting reactor was analyzed, and the formula of current changing in short circuit transient process was deduced; according to the current changing formula, an engineering calculation formula of current limiting reactors impedance was derived. The case calculation shows that current limiting reactor meeting the need of the engineering calculation formula can reach the system current limiting requirement.

• Periodical: Advanced Materials Research (Volume 722)
• Pages: 223-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.722.223
• Online since: July 2013
• Authors: Tie Ying Zhao, Yan Wen Wang
• Keywords: Current Limiting Reactor, Power System, Short Circuit, Transient Analysis

References

[1] Sun SM, Liu HS, Li QM (2008) A Summarization of research on fault current limiter of power system. Power System Technology 32(21):75-79

[2] Zhou XS, Xiang LR, Ma YJ, et al (2004) The development and application of fault current limiting device. Transactions of China Electrotechnical Socitey 19(11):1-7

[3] Liu K, Chen HK, Lin J, et al (2010) Study situation of applications of fault current limiter in power system. Power System Protection and Control 38(7):147-151

[4] Jiang DZ, Ao ZX, Lu XR, et al (2007) Research and development of short-circuit current limiting technology. Proceedings of the CSU-EPSA 19(6): 8-19,87

[5] Yin K, Gao K (2004) Analysis of using series reactor to limit 500kV short-circuit current. East China Electric Power 32(9):7-10

[6] Chen SM, Xu W,Wang ZX, et al (2008) Effects of 500 kV current-limiting inductors on transient recovery voltage and its countermeasures. North china electric power (1):11-15

[7] Yang F (2005) Study of advantage of dry type air core current limiting reactor. East china electric power 33(5): 38-40

[8] Chen SM, Wang W, Yang PC (2010) Effects of current-limiting inductor on power frequency over voltages in Transmission Line. Power System Technology 34(3):193-196

[9] Liu HS, Li QM, Lou J, et al (2007) Impact of inductive FCL on the RRRV of circuit breakers .Transactions of China Electrotechnical Socitety 22(12):84-91.

[10] Cai SZ, Zhang W, Zhao CH, et al (2010) Impacts of fault current limiter on overvoltage in distributed generation. Electrical & Electronics (10):32-34,43

[11] Yang ZY, Chen S, Li R (2011) 500 kV fault current limiter's impacts on protection and solution. Electrical & Electronics (6):9-42

[12] Zhao ZY (2005) Research on power solid state current limiter. Zhe Jiang University, Hangzhou

[13] Feng RH, Feng ML, Kong JS (2008) Based on current rate of change of short-circuit protection methods. Coal Mine Machinery 29(5):171-173
