A Review of Harvesting Green Energy from Road

Abstract:

This paper presents a review of harvesting green energy from road. There are three forms of green energy exist in road: light, thermal and mechanical energy. Photovoltaic technology, thermoelectric technology, directly heat transferring and piezoelectric technology are discussed in this paper, as well as the cases studied in Europe, USA, Japan, Israel and China. Solar panels installed along road are current available to harvest light energy from the roadside land. Alternatively, the solar panels can be installed on the road instead of pavement structures, such as the Solar Roadway^TM. This technology is rather conceptual at this moment, and the main challenge is to design and build durable materials and structures that can withstand traffic at a reasonable maintenance and replacement cost. Thermoelectric generators can potentially be embedded in pavements, and generate electric power from the temperature gradient existing in pavements. However, instrument capable of efficiently generate electricity from the relatively small temperature gradient in pavement is still under development. Directly heat transfer solution is to have fluid flow through pavement, and the fluid is heated (in summer) by the pavement. An extra benefit in addition to energy collection is that this method can reduce pavement temperature as well as the associated negative effects on pavement performance and the environment. However how the heated fluid can be utilized was not clear. Electricity can be generated by piezoelectric ceramic generators embedded in pavement, as a result of the compressive stress and deformation induced by moving vehicles. Trials have been reported in Israel and China, and it was estimated that one lane-mile of highway can potentially general electricity of 200 kW.

• Periodical: Advanced Materials Research (Volume 723)
• Pages: 559-566
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.723.559
• Online since: August 2013
• Authors: Hong Duo Zhao, Jiang Ming Ling, Peng Cheng Fu
• Keywords: Energy Harvesting, Light Energy, Mechanical Energy, Road, Thermal Energy

References

[1] Yiming Liu, Active energy harvesting, Submitted in partial fulfillment of the requirements for the degree of doctor of philosophy, Pennsylvania State University, 2006.

[2] O. Yaglioglu, Modeling and design considerations for a micro-hydraulic piezoelectric power generator, master's thesis, Dept. Electrical Eng. and Computer Science, Massachusetts Inst. Of Technology, 2002.

[3] R.D. Kornbluh et al., Electroelastomers: applications of dielectric elastomer transducers for actuation, generation and smart structures, Smart Structure and Materials 2002: Industrial and Commerical Applications of Smart Structures Technologies, Proc. SPIE, vol. 4698, Int;l Soc. Optical Eng., 2002, pp.254-270.

DOI: 10.1117/12.475072

[4] Roger A. Messenger, Jerry Ventre, Photovoltaic systems engineering, CRC Press, New York, 2010.

[5] Oregon Department of Transportation (ODOT). Oregon solar highway, http://www.oregon.gov/ODOT/HWY/OIPP/docs/OregonInspiration.pdf, 2012.7.20.

[6] RenewableEnergyWorld.com. PV you can drive on: promising technology in solar roads. http://www.renewableenergyworld.com/rea/news/article/2008/03/pv-you-can-drive-on-promising-technology-in-solar-roads-51755, 2012.7.20.

[7] Solar Roadway™, http://solarroadways.com/intro.shtml, 2012.7.20.

[8] Shashank Priya, Daniel J. Inman, Energy harvesting technologies, Springer, New York, 2009.

[9] Ongel, A. and Harvey, J.T. Analysis of 30 years of pavement temperatures using the enhanced integrated climate model (EICM), Draft report prepared for the California Department of Transportation, Pavement Research Center, Institute of Transportation Studies, University of California Berkeley, University of California Davis, UCPRC-RR-2004/05, 2004.

[10] Sevan Karabetoglu, Altug Sisman, Z. Fatih Ozturk, Turker Sahin. Characterization of a thermoelectric generator at low temperatures. Energy Conversion and Management, 2012.

DOI: 10.1016/j.enconman.2012.04.005

[11] Guangxi Wu and Xiong Yu. Thermal Energy Harvesting Across Pavement Structure. TRB 91st Annual Meeting Compendium of Papers DVD, 12-4492, 2012, Washington, DC.

[12] M. Hasebel, Y. Kamikawa and S. Meiarashi, Thermoelectric Generators using solar thermal energy in heated road pavement, 25th International Conference on Thermoelectrics, IEEE, 2006.

DOI: 10.1109/ict.2006.331237

[13] Mallick R.B., Chen B.-L., and Bhowmick S., Harvesting energy from asphalt pavements and reducing the heat island effect. International Journal of Sustainable Engineering; 2(3):214-228, 2009.

DOI: 10.1080/19397030903121950

[14] R. Mallick, J. Carelli, L. Albano, S. Bhowmick & A. Veeraragavan, Evaluation of the potential of harvesting heat energy from asphalt pavements. International Journal of Sustainable Engineering, Vol. 4(2): 164-171, 2011.

DOI: 10.1080/19397038.2010.550336

[15] dr.ir. A.H. de Bondt, ing. R. Jansen. Generation and saving of energy via asphalt pavement surfaces. Ooms Nederland Holding bv, http://www.roadenergysystems.nl/, 2012.7.20.

[16] Morgan Electro Ceramics, Introduction piezoelectric ceramics, 2001.

[17] Innowattech 's solution - The Innowattech piezo electric generator (IPEG™), http://www.innowattech.co.il/index.aspx, 2012.7.20.

[18] Hongduo Zhao, The concept of harvesting energy from pavement: the piezoelectric way, Presentation at 2010 FAA Worldwide Airport Technology Transfer Conference, 2010.

[19] Hongduo Zhao, Jian Yu, and Jianming Ling, Finite element analysis of cymbal piezoelectric transducers for harvesting energy from asphalt pavement, Journal of the Ceramic Society of Japan, Vol. 118(10): 909-915, 2010.

DOI: 10.2109/jcersj2.118.909
