Design and Implementation of a High Power Battery Charger of a Hydroelectric-Connected PV Plant

Abstract:

In remote areas, the scheme of networking grid complementarily by the large capacity ofPV plants and the hydropower units becomes an important choice. After analyzing the design of ahydroelectric-connected PV plants, this paper presents a detailed requirement of a large capacitybattery charger. The Buck circuit topology is adopted as the topology of the battery charger satisfyingthe demand the high charging efficiency and reliability and a 3 phase phase-shifted interleavingtopology is adopted to resolve the problem of high power application. Finally a double-loop controlstrategy was designed for implementing the batteries three-stage charging control and PV MPPTfunction. A 150kW battery charger is developed and used in PV plant of the Yushu, Qinghai province,China. The experimental data acquired form

• Periodical: Advanced Materials Research (Volumes 724-725)
• Pages: 137-140
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.724-725.137
• Online since: August 2013
• Authors: Chang Bin Ju, Huan Wang, Wei Feng, Hong Hua Xu
• Keywords: Battery Charger, Buck Topology, Interleaving Technology

References

[1] W. El-Khattam, M. Salama. "Distributed Generation Technologies, Definitions and Benefits". Electric Power Systems Research, 2004, 71(2): 119-128.

DOI: 10.1016/j.epsr.2004.01.006

[2] B.H. Cho, and B. Choi, "Analysis and Design of Multi-Stage Distributed Power Systems", INTELEC'91 Proc., Nov. 1991, pp.68-76.829-850.

[3] Ned Mohan, Tore M.Undeland and William P. Robbins, "Power Electronics Converters, Applications and Design" (2nd ed.) New YorkWiley & Sons, 1995 p.745.

[4] Sam G. Parler, Jr, Cornell Dubbilier, "Improved Spice Models of Aluminum Electrolytic Capacitors for Inverter Application" Presented at IEEE Industry Application Society Conference. Oct. 17 (2002)

DOI: 10.1109/ias.2002.1042783

[5] B. Irving, M. Jovanovich, "Analysis, Design, and Performance Evaluation of Droop Current-Sharing Method, " IEEE APEC '00Proceedings, February 2000, pp.235-241

[6] Y. Panov, J. Rajagopalan, F. C. Lee, "Analysis and Design of N Paralleled DCIDC Converters with Master-Slave Current Sharing Control, " IEEE APEC '97 Proceedings, February 1007, pp.436-442

DOI: 10.1109/apec.1997.581489

[7] Y. Panov, M. Jovanovich, "Stability and Dynamic Performance of Current-Sharing Control for Paralleled Voltage Regulator Modules", IEEE APEC .01 Proceedings, March 2001, pp.765-771

DOI: 10.1109/apec.2001.912456

[8] Yuri Panov and Milan M. Jovanovic, "Loop Gain Measurement of Paralleled DCIDC Converters with Average-Current-Sharing Control,"IEEE Transactions on Power Electronics, Vo123, No 6, Nov. (2008)

DOI: 10.1109/tpel.2008.2002955
