Asymmetric Voltage Sag Control Strategy for Grid-Connected PV System Based on PIR Controller

Abstract:

This paper proposes an improved LVRT control strategy based on PIR controller for grid-connected photovoltaic system under asymmetric voltage sag fault. First, the PIR current controller is designed in the positive synchronous frame without the need to decompose the positive and negative sequence components and the dynamic adjustment method for the current-reference calculation is given in order to gain a constant active power. And then, the principle how control strategies switching between the one in normal state and the other one in fault state is revealed in detail. Finally, simulations and experiment test on a 500kVA grid-connected photovoltaic inverter verify that this control strategy achieves good dynamic performance and it improves the PV inverters’ capacity of riding through asymmetric voltage sag fault effectively.

• Periodical: Advanced Materials Research (Volumes 724-725)
• Pages: 128-131
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.724-725.128
• Online since: August 2013
• Authors: Fei Zheng, Xiao Lin Zhang, Ming Chang Ding
• Keywords: Asymmetric Voltage Sag, Control Strategy Switching Method, Dynamic Adjustment Method, Grid-Connected Photovoltaic System, PIR Controller

References

[1] Carrasco, J.M.. IEEE Trans on Industrial Electronics, 2006, 53(4):1002-1016

[2] Ruifeng Yan, Saha, T.K. . IEEE Trans on Power Systems, 2012, 27(2): 1078-1089.

[3] Wenchang Shao; Ruiming Wang; Qing Li, et al. Transient behavior analysis of Doubly-fed induction generator under asymmetric voltage dips and testing validation[C]. 2010 International Conference on Proceedings of the Power System Technology.

DOI: 10.1109/powercon.2010.5666559

[4] Gabe, I.J.; Palha, F.F.K. Grid connected voltage source inverter control during voltage dips[C]. 35th Annual Conference of IEEE on Industrial Electronics.2009:4571-4576

DOI: 10.1109/iecon.2009.5414865

[5] Reyes, M.; Rodriguez, P..IEEE Trans on Power Electronics,2012, 27(9): 3934-3943

[6] Roiu, D.; Bojoi, R.; Griva, G..Improved Control Scheme for Three Phase PWM AC/DC Converter under Asymmetric Voltage Dips Conditions[C]. 11th International Conference on Optimization of Electrical and Electronic Equipment, 2008:143-148

DOI: 10.1109/optim.2008.4602401

[7] HU J, HE Y, XU L, et al.. IEEE Trans on Industrial Electronics,2009,56(2): 439-451

[8] Liu Yi. Modeling and Simulation of PV Grid-connected Generation System. BeiJing: Beijing Jiaotong University, (2011)

[9] Hong-seok Song,Kwanghee Nam.IEEE Trans On Industrial Electronics 1999,46(5):953-959．

DOI: 10.1109/41.793344

[10] Yuan Xufeng. Proceedings Of The Chinese Society For Electrical Engineering (In Chinese), 2008, 28(1):52-58
