Design and Full-Scale Test for Cup-Type Steel Tubular Tower of UHV Transmission Line in Heavy Icing Area

Abstract:

The ZB1 cup-type steel tubular tower is the first single-circuit tower for UHV transmission line in heavy icing area. Except the ground supports, steel tubular are applied in whole tower. The plug-in boards and forging flanges are used in ZB1 tower,and the highest strength of tubular steel is Q345. Through the monographic study on the tower optimizationnode structuretowers Eiffel effect and bending moment at member end et., The design of ZB1 cup-type steel tubular tower is improved. The success of full-scale test verified the reliability in design and manufacture of cup-type steel tubular tower for UHV in heavy icing area. Research results of this paper can be applied in UHV transmission line projects.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1074-1080
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1074
• Online since: August 2013
• Authors: Zi Fu Zhang*, Jing Bo Yang, Feng Li Yang, Qing Hua Li
• Keywords: Cup-Type, Full-Scale Test, Heavy Icing Area, Steel Tubular Tower, UHV

References

[1] Zhusen Sun，Yongfeng Cheng，Qiang Zhang，Xilai Li，Ming Li，Jingbo Yang，Huchang Wang and Yin Ye: Application and Dissemination of Steel Tubular Tower in Transmission Lines, Power System Technology. 34(2010)186-192(In Chinese).

[2] Southwest Power Design Institute of China Power Engineering Consulting Group Corporation: Feasibility Research of Yaan～Nanjing South 1000kV AC Ultra-high Power Transmission Engineering, edited by State Grid Corporation, Chengdu(2009).

[3] China Electric Power Research Institute and Southwest Power Design Institute of China Power Engineering Consulting Group Corporation: Key Technology Research on Design of Ultra-high Voltage Power Transmission Tower in Heavy Ice Area, edited by State Grid Corporation, Beijing(2011).

DOI: 10.17775/cseejpes.2017.01200

[4] Construction Ministry of People's Republic of China and General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China: Design Rule of Steel Structure, edited by China Planning Press, Beijing(2003).

[5] Baiping Dong and Yiyi Chen: Stability Capacity Calculation of Circular Steel Tube Beam-columns under Biaxial Bending, Industrial Construction. 40(2010)107-111(In Chinese).

[6] Qinghua Li，Jingbo Yang and Junke Han，et a1. Design and Full-scale Test for Steel Tubular Tower of UHV and EHV Quadruple-circuit Transmission Lline on the Same Tower , Electric Power. 45(2012)14-17(In Chinese).

DOI: 10.4028/www.scientific.net/amr.732-733.1045

[7] National Development and Reform Commission of the People's Republic of China: Design Technical Rules for Overhead Power Transmission Line Tower, edited by China Power Press, Beijing(2002) (In Chinese).
