Decoupling Droop Control Method for Power Distribution of Microgrid

Abstract:

How to ensure the security, stability and economic operation of microgrid in different operation modes is a difficult problem of microgrid research. There is active power and reactive power coupling in the regulation of frequencies and voltages because of the line parameter characteristics of microgrid. The defect of the traditional active power-frequency, reactive power-voltage droop control is analyzed and a novel decoupling droop control method for low voltage microgrid is proposed in this paper. At last, the multiple feedback loop control strategy for inverters on the basis of this proposed method and a microgrid simulation model are established. The comparative analysis between the new method and the traditional method based on the simulation results can prove that the proposed control method is simple in design, and it can assure an excellent power quality and realize the reasonable distribution of active power and reactive power between distributed generations.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1354-1357
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1354
• Online since: August 2013
• Authors: Shi Wang Yang*, Peng Li, Chang Wang, Jia Ming Li
• Keywords: Decoupling Control, Droop Control, Microgrids (MGs), Power Distribution

References

[1] Wang Chengshan, Xiao Zhaoxia, Wang Shouxiang, Multiple feedback loop control scheme for inverters of the micro source in microgrids, , Transactions of China Electrotechnical Society, In Chinese, vol. 24, pp.100-107, Feb. (2009).

[2] Sao C., Lehn P., Control and power management of converter fed microgrids, in Power and Energy Society General Meeting, 2010 IEEE , p.1.

DOI: 10.1109/pes.2010.5589610

[3] De Brabandere, K. Bolsens, B., Van den Keybus, J., Woyte, A., Driesen, J., Belmans, R., Leuven, K. U, A voltage and frequency droop control method for parallel inverters, Power Electronics Specialists Conference, 2004. PESC 04. 2004 IEEE 35th Annual, vol. 4, pp.2501-2507.

DOI: 10.1109/pesc.2004.1355222

[4] MouXiaochun, Bi Daqiang, RenXianwen, Study on control strategies of a low voltage microgrid, Automation of Electric Power Systems, In Chinese, vol. 34, pp.91-96, Oct. (2010).

[5] Wang Chengshan, Xiao Zhaoxia, Wang Shouxiang, Synthetical Control and Analysis of Microgrid, Automation of Electric Power Systems, In Chinese, vol. 32, pp.98-103, Apr. (2008).

[6] Li Yan，LiYunwei. Virtual frequency voltage frame control of inverter based low voltage frame control of inverter based low voltage microgrid, Proceedings of the IEEE Electrical Power&EnergyConference，October 22 23，2009，Montreal，Canada, pp.1-6.

DOI: 10.1109/epec.2009.5420973
