Geometric Parameterization Technique Based Continuation Power Flow and its Applications in AC/DC Hybrid Power System

Abstract:

A new continuation power flow method based on local geometric parameterization technique is proposed for voltage stability analysis of AC/DC hybrid power system. By means of the alternating iteration method as the AC/DC power flow algorithm, the proposed method takes the coupling relationship between AC and DC systems into account to modify Jacobian matrix of AC system. Constraints of variables in DC system are also considered, as well as the adjustment of converter transformers tap position and the conversion of converters control modes. Based on the predictor-corrector method, this paper adopts the geometric corrector, and changes the direction of convergence effectively. According to different operation modes of AC/DC system, accurate voltage stability limit and the entire PV curve can be acquired. Simulation results of IEEE test systems are used to show the validity of the proposed algorithm.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 857-863
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.857
• Online since: August 2013
• Authors: Chao Jie Guan, Jin Quan Zhao, Jian Hua Yin, Kun Men, Chao Hong
• Keywords: AC/DC, CPF, Geometric Parameterization, PV Curve, Voltage Stability
