Intensifying Magnetic Separation of Iron-Bearing Sulfide Minerals by Electron Beam Irradiation Pretreatment

Abstract:

The changes of magnetic property of several iron bearing sulfide minerals after strong beam current electron irradiation are examined. Data shows that the magnetic susceptibility of arsenopyrite and chalcopyrite increases markedly compared to that of pyrite and marmatite. The magnetic susceptibility of arsenopyrite exceeds the lowest ferromagnetic limit 3000 cm³/g, while the susceptibility changes of other minerals are relatively slow. The irradiation dose is the dominate parameter determining the magnetic susceptibility change. Electron beam irradiation might be a potential method to enlarge the magnetic property distinction between the minerals for their magnetic separation.

• Periodical: Advanced Materials Research (Volumes 734-737)
• Pages: 945-949
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.734-737.945
• Online since: August 2013
• Authors: Huai Fa Wang*, Shou Ci Lu, Cai Li Wang
• Keywords: Electron Beam Irradiation, Iron Bearing Sulfide, Magnetic Separation, Magnetic Susceptibility

References

[1] S. Y. Liu, Principle of Magnetic and electrical Beneficiation (in Chinese) [M], Centralsouth University of Technology Press, Changsha, China, 1994.

[2] S. C. Lu，Separation Engineering of mineral particle [in Chinese], Metallurgy Industry Press, Beijing, (1990).

[3] Wang, H; Bochkarev, GR; Rostovtsev, VI; Veigel't, YP; Lu, S.Intensification of polymetallic sulfide ore dressing by high-energy electronsJOURNAL OF MINING SCIENCE, 38 (5): 499-505 SEP-OCT 2002.

[4] G.R. Bochkarev, V.A. Chanturiya, and V.E. Vigdergaus et al ., Prospects of Electron Accelerators Used for Realizing Effective Low—cost Technologies of Mineral Processing, [in]H. Hoberg and H.V. Blottnitz eds., Proceedings of the ⅩⅩ IMPC. Aachen, Germany, 1997, P231.

[5] G.R. Bochkarev, Yu.P. Vegelt and V.I. Rostovtsev. Phase Conversions in Sulfide Ores on Combined Irradiation and Heating. Journal of Mining Science. 36(2000),No.1,p.81.

DOI: 10.1007/bf02551144

[6] P.E. Ostopenko, A.R. Smolyakov, and I.M. Trufanova, et al , Directional Change of Technological Properties of Rare Metal Mineral By Means of the Radiation—Thermal action, Journal of Mining Science, 29(1993), No.1. p.107.

[7] Ivan Florek and Vladimir Cerny, Intensification of the Magnetic Separation of Fine Chalcopyrite Ores by Means of Irradiation by Electrons,[in] Proceedings of the First International Conference on Modern Process Mineralogy and Mineral Processing, September 22—25,1992, Beijing, China. P.358.

[8] Wang, H; Lu, S,A new approach to electrification of powdered minerals by electron beam irradiation, JOURNAL OF MINING SCIENCE, 39 (4): 405-409 JUL-AUG 2003.

DOI: 10.1023/b:jomi.0000023194.22130.23

[9] G.R. Bochkarev, V.I. Rostovtsev, and Yu. P. Veigel't et al, Effects of Accelerated Electrons on Structural and Technological Properties of Ores and Minerals, Journal of Mining Science, 28(1992), No.6, p.571.
