Mechanical Analyses of Advanced Multi-Chip Embedded Wafer Level Packages

Abstract:

ncreasing functionality accompanied with device miniaturization in microelectronics has led to increased market demand for packages with small form factor. Over the years, embedded wafer level packaging (EWLP) has become an attractive option since it allows a reduction in package size and height. In the EWLP approach, the singulated dies are embedded within the molding compound through the wafer level compression molding process. For this study, critical mechanical challenges such as die shift and thermal cycling performance of a multi-chip embedded wafer level package (MCEWLP) are addressed through numerical modeling. For improved accuracy in die shift predictions, both mechanical effects and fluidic effects need to be taken into account. Mechanical effects account for around 75% of the die shift while fluidic effect contributes to the remaining 25%. It is shown that reducing the die size and the inclusion of UBM as a buffer layer can effectively increase the fatigue life of the packages.

• Periodical: Advanced Materials Research (Volume 740)
• Pages: 289-294
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.740.289
• Online since: August 2013
• Authors: Siow Ling Ho, Lin Bu, Dexter Velez Sorono, Ser Choong Chong, Tai Chong Chai, Xiao Wu Zhang
• Keywords: Design, Die Shift, Electronics Packaging, Embedded Wafer Level Packages, Finite Element Method (FEM), Numerical Analysis, Re-Configured Wafer, Thermal Fatigue

References

[1] Brunnbauer M, Furgut E, Beer G, Meyer T, Hedler H, Belonio J, Nomura E, Kiuchi K, Kobayashi K. An embedded device technology based on a molded reconfigured wafer. Electronic Components and Technology Conference, 2006. Proceedings. 56th, 2006. p.5 pp.

DOI: 10.1109/ectc.2006.1645702

[2] Chee Houe K, Kumar A, Xiaowu Z, Sharma G, Vempati SR, Vaidyanathan K, Lau JHS, Dim-Lee K. A novel method to predict die shift during compression molding in embedded wafer level package. Electronic Components and Technology Conference, 2009. ECTC 2009. 59th, 2009. p.535.

DOI: 10.1109/ectc.2009.5074066

[3] Hyoung Joon K, Ser Choong C, Ho DSW, Yong EWY, Chee Houe K, Teo CWL, Fernandez DM, Guan Kian L, Vasarla NS, Lee VWS, Vempati SR, Navas KOK. Process and reliability assessment of 200 micro m-thin embedded wafer level packages (EMWLPs). Electronic Components and Technology Conference (ECTC), 2011 IEEE 61st, 2011. p.78.

DOI: 10.1109/ectc.2011.5898495

[4] Jing-En L, Yonggang J, Kim-Yong G, Yiyi M, Guojun H, Yaohuang H, Baraton X. Challenges for extra large embedded wafer level ball grid array development. Electronics Packaging Technology Conference, 2009. EPTC '09. 11th, 2009. p.202.

DOI: 10.1109/eptc.2009.5416551

[5] Kumar A, Xia D, Sekhar VN, Lim S, Chin K, Sharma G, Rao VS, Kripesh V, Lau JH, Dim-Lee K. Wafer level embedding technology for 3D wafer level embedded package. Electronic Components and Technology Conference, 2009. ECTC 2009. 59th, 2009. p.1289.

DOI: 10.1109/ectc.2009.5074177

[6] Mazuir J, Olmeta V, Yin M, Pares G, Planchais A, Inal K, Saadaoui M. Evaluation and optimization of die-shift in Embedded Wafer-Level Packaging by enhancing the adhesion strength of silicon chips to carrier wafer. Electronics Packaging Technology Conference (EPTC), 2011 IEEE 13th, 2011. p.747.

DOI: 10.1109/eptc.2011.6184519

[7] Sharma G, Kumar A, Rao VS, Soon Wee H, Kripesh V. Solutions Strategies for Die Shift Problem in Wafer Level Compression Molding. Components, Packaging and Manufacturing Technology, IEEE Transactions on 2011;1:502.

DOI: 10.1109/tcpmt.2010.2100431

[8] Th EK, Hao JY, Ding JP, Li QF, Chan WL, Ho SC, Huang HM, Jiang YJ. Encapsulation challenges for wafer level packaging. Electronics Packaging Technology Conference, 2009. EPTC '09. 11th, 2009. p.903.

DOI: 10.1109/eptc.2009.5416414

[9] Vianco PT. Fatigue and Creep of Lead-Free Solder Alloys: Fundamental Properties. In: Shangguan D, editor. Lead-Free Solder Interconnect Reliability. 2005.

[10] Syed A. Accumulated creep strain and energy density based thermal fatigue life prediction models for SnAgCu solder joints. Electronic Components and Technology Conference, 2004. Proceedings. 54th, vol. 1, 2004. p.737.

DOI: 10.1109/ectc.2004.1319419
