FEM Analysis of Bi-Prestressed Concrete Beam

Abstract:

Based on ANSYS software, the solid modeling method was performed to build the half model of bi-prestressed concrete beam. And the solution for solve the problem such as the constitutive equation, failure criteria , the method of modeling,the infliction method of prestressed was summarized in this paper. The heating-cooling method was used to achieve the bi-prestressed.The simulate method was reasonable while the built mode was performed to simulate the pre-arch and bearing capacity, simulate the pre-arch and bearing capacity of pre-pressed bi-prestressed concrete beam by FEM software ,and compared with the experiment results. And summarized the handling of the constitutive equation,failure criteria,the infliction method of prestressed, the method of modeling ,and so on. All of the method will provide reference for the research of Bi-prestressed concrete beam.

• Periodical: Advanced Materials Research (Volume 743)
• Pages: 138-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.743.138
• Online since: August 2013
• Authors: Feng Gao, Tong Liu
• Keywords: Bi-Prestressed, Finite Element Method (FEM), Pre-Arch, Pre-Pressed

References

[1] Nan Wang. 40 m bi- prestressed concrete simply supported beam bridge static and dynamic load test research[J]. engineering mechanics, 2003 (supplementary issue): 112-115.

[2] Miaonian Wu, Kechang Chen. Pre-pressed bi- prestressed concrete simply supported beam [J]. Shang Hai highways, 1997(1): 22-25.

[3] Wenzhong Zhen , Jingbo An, Ying Wang. Design of bi- prestressed concrete structure though theoretical study[J]. China Journal of Highway and Transport , 2002(4): 35-37.

[4] Shao Wei. Theoretical and experiment study of bi- prestressed concrete beam[D]. Tianjin： Tianjin university, (2007).

[5] Wei Mao, JinQing Jia , Fang Yu. numerical simulation of prestressed concrete beam based on disjunctive model[J]. Railway Engineering , 2011(7): 17-19.

[6] Xinming Wang. Engineering structure numerical analysis by ANSYS[M]. BeiJing: China Communications Press, (2007).

[7] Jianshu Ye, Guanhua Fu, Yuefeng Ma, et. Pre-pressed reinforcement anchoring research of bi- prestressed concrete beam[J]. Highway traffic science and technology, 2000, 17(3): 21-24.

[8] Man Zhao, XinmingWang , Jing Gao. FEM numeric analysis of prestressed concrete structure [J]. Journal of Shijiazhuang Railway Institute , 2004(1): 84-88.
