The Analytical Research and Development of On-Line Monitoring Models of Thermal State for Turbine Rotor

Abstract:

Steam turbine units are required to start up and shut down as fast as possible to improve economy and load-response ability of the units under the qualification of safety. it is important to monitor and control thermal state in turbine during operation, especially during the process of start-up and shutdown. Thermal stresses in turbine rotor in thermal power plants are the limiting factors for rapid startup, shutdown or load change. In this paper the online calculation models of temperature and thermal stress for a two-dimensional axis-symmetric object are obtained after disposing of the nonlinear factor such as temperature-dependent properties by a transformation. The model gained can be used to analyze thermal states in thick-walled components, monitoring and control online.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 105-109
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.105
• Online since: August 2013
• Authors: Shi Liu, Heng Liang Zhang, Yan Zhou, Dan Mei Xie
• Keywords: Online Monitoring Model, Temperature Dependent, Transformation, Turbine Rotor

References

[1] N.K. Mukhopadhyay, B.K. Dutta and H.S. Kushwaha: On-line Fatigue–creep Monitoring System for High-temperature Components of Power Plants. International Journal of Fatigue, vol. 23(2001), p.549–560.

DOI: 10.1016/s0142-1123(01)00009-3

[2] S Zucca, D Botto and M. M Gola: Faster on-line Calculation of Thermal Stresses by Time Integration". International Journal of Pressure Vessels and Piping, vol. 81(2000) , p.393–399.

DOI: 10.1016/j.ijpvp.2004.03.012

[3] NK Mukhopadhyay, BK Dutta, HS Kushwaha, SC Mahajan and A Kakodkar: On Line Fatigue Life Monitoring Methodology for Power Plant Components". Int J Press Ves Piping, vol. 60(1994), p.297–306.

DOI: 10.1016/0308-0161(94)90129-5

[4] K. L Chen and A. Y Kuo: Green's Function Technique for Structures Subjected to Multiple Site Thermal Loading. Struct Mech Reactor Technol, vol. 11(1989), p.353–8.

[5] K Sakai, K Hojo, A Kato and R Umehara: On-line Fatigue-monitoring System for Nuclear Power Plant. Nucl Eng Des, vol. 153(1994), p.19–25.

DOI: 10.1016/0029-5493(94)90017-5

[6] D Botto, S Zucca and M. M Gola: a Methodology for On-line Calculation of Temperature and Thermal Stress under Non-linear Boundary Conditions. Int J Press Vessels Piping, vol. 80(2003), p.21–9.

DOI: 10.1016/s0308-0161(02)00139-4

[7] H. L Zhang: the Research and Development of High-Quality Thermal-Stress Online Monitoring Model for 600MW Turbine Rotors. Proceedings of the CSEE, 2006, 1.
