Simulation and Experiment Research of Working Process of Exhaust Turbocharged and Intercooled Diesel Engine

Abstract:

In this paper, the working process mathematical models of in-cylinder of the diesel engine, exhaust turbocharger and intercooler are established, as well as the simulating model using simulation Software GT-POWER. Through parameters modification, we built the Map of efficiency characteristic curve of compressor and turbocharger. Targeted at the turbocharged intercooled diesel engine of YC4F92 type, simulating calculation and experimental verification are conducted. It turned out that the simulating value and experimental value matches well and the maximum error value is not more than 5%, which demonstrated the accuracy and reliability of the established model. The established model can works as a tool for the design and optimization of diesel engine.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 13-17
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.13
• Online since: August 2013
• Authors: Meng Xiang Liu, Peng Wang, Fang Yuan
• Keywords: Diesel Engine, GT-Power, Intercooler, Modeling, Simulation, Thermodynamic Process, Turbocharger

References

[1] Li Jun. Advanced Energy Saving and Emission Reduction Technology of Automotive Engine [M]. Beijing: Beijing Institute of Technology Press, 2011(chinese).

[2] Li Yanhong. Prediction of Direct Injection Diesel Engine's Performance and Its Parameters Optimization [Jiangsu University Master Thesis]. Jiangsu University, 2003(chinese).

[3] Weiss J. Engine Cycle Simulation Application in the Development of Truck Engine. Foreign Internal Combustion Engine, 2004 (5): 41-43(chinese).

[4] Zhu Fangjun, Wu Jian. Numerical Calculation and Optimization of Work Process of Internal Combustion Engine. Beijing: National Defence Industry Press, 1997(chinese).

[5] Gong Jin-ke, Liu Meng-xiang, LIU Xiang-ling. The Mathematical Simulation for Diesel Engine Working Process[J]. Mobile Power Supply and Vehicle, 2002(2): 11-13(chinese).

[6] Gong Jin-ke, Liu Meng-xiang, Liu Xiang-ling. Diesel Engine Modeling and Simulation Using Software Simulink[J]. Journal of Hunan University, 2002(4): 38-41(chinese).

[7] Liu Yongchang. Simulation of Thermodynamic Process of Internal Combustion Engine [M]. Machinery Industry Press, 2001(chinese).

[8] Liu Mengxiang. Modeling and Simulation of Diesel Engine and It's Control System Based on SIMULINK[Hunan University Master Thesis]. Hunan University, 2001(chinese).
