Three-Dimensional Simulation of the Intake Port Combination Effect on Intake Flow Characteristic in a Highly Intensified Diesel Engine

Abstract:

In this paper, the three-dimensional CFD method is used in numerical simulation of the highly intensified diesel engine intake process. The effect of different intake flow compound modes on the highly intensified diesel engine is studied (Including compounded port with helical and tangential intake port, compounded port with two helical intake ports and compounded port with two tangential intake ports). By contrasting the instantaneous flow field, flow characteristic and inlet ability of the three compound modes, the pattern of influence on the inlet flow characteristics by compound modes is analyzed. The results indicate that the combinations of the intake port greatly affect the swirl rate and the inlet ability. The interference of the two helical intake ports is serious, causing more inlet loss. The two helical intake ports have the weakest inlet ability among the three types of intake ports. However, two helical intake ports can cause higher swirl rate. Two tangential intake ports inlet ability is the most excellent, but its swirl rate is the lowest.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 211-214
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.211
• Online since: August 2013
• Authors: Hong Meng Li, Guo Xiu Li, Yuan Jing Hou, Yu Song Yu
• Keywords: Combinations of Intake Port, Flow Characteristic, Highly Intensified Diesel Engine

References

[1] DUAN Jiaxiu, RAO Mingfa, XU Sidu, LI Yuanhong. A Study of the Influence of the Different Inlet - Port Combination the Swirl Ratio and Airflow in the Four - Valve Diesel Engine. [J] Internal Combustion Engine Engineering 2002(5): 51-55.

[2] HU Yun-ping, LI Qiu-xia, 3D Transient Numerical Simulation of Flow Field in Cylinder of Diesel Engine with Double-intake Port. [J] Agricultural Equipment &Vehicle Engineering 2010(3). 30-37.

[3] WU Zhi-jun, SUN Ji-mei, HUANG Zhen. Effect of Disturbance between Two Intake-Ports on Intake-Ports Valve Exit Flow-Field in Four-Valve Diesel Engine. [J] Journal Of Shanghai Jiaotong University. 2001. 5: 754-757.

[4] WU Zhi-jun, SUN Ji-mei, HUANG Zhen. The Experiment Study Of The Interference Of The Two Inlet Valve In DI Diesel Engine With 4 Intake Valve. [J] Internal Combustion Engine. 2001, 19(6): 517-520.

[5] LI Yu-feng, GONG Xiao-hui. A Study of the Influence of the Different Inlet - Port Combination And Position On the Swirl in the Four - Valve Diesel Engine. [J] Internal Combustion Engine, 2001, 19(3): 209-214.

[6] LI Jun, WANG LI-jun etc, al. The Velocity Distribution Of The Intake Flow Nearby The Valve Exit in the Four - Valve Diesel Engine. [J] Agricultural Machinery Engineering，2002, 33(1): 5-8.
