Design of Wireless Monitoring Environment System Based on AVR SCM

Abstract:

The system had achieved a wireless data communication function using AVR SCM as a control center and basing on radio frequency identification technology. The transmitting terminal of system produces a high frequency signal through capacitance connecting three point type oscillator. And the encoded signal will be transmitted after high-frequency carrier modulated. While after the receiving terminal receive the signal through antenna, and the signal after a series processes including amplification, detection, rectification, voltage comparison will be processed by SCM. The system includes temperature humidity sensor, clock generator chip, photosensitive element, could detect the surrounding environment signal and wireless transmit. The paper elaborates the soft and the hardware realizing specific course of the wireless transmission system. It has an important meaning for the wireless transmission technique.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 532-535
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.532
• Online since: August 2013
• Authors: Chun Wu Wang, Chun Ling Liu, Zheng Kun Qin
• Keywords: AVR SCM, Monitoring Environment, Wireless Transmit- Receive

References

[1] KONG Ling-young: Journal of Chongqing University of Arts and Sciences (Natural Science Edition), vol. 27(2008), p.47.

[2] HE Yong, CHEN Lei: Journal of DongHua University(Natural Science), vol. 35(2009), p.194.

[3] FAN Jianming, Chen Yuanrui: Foreign Electronic Measurement Technology, vol. 25(2006), p.4.

[4] ZHANG Zhonghua, WANG Zeyong, GAO Xiaorong, et al.: Modern Electronics Technique, No. 17 (2009), p.137.

[5] Sun Huan, Teng Zhaosheng: Foreign Electronic Measurement Technology, Vol. 25(2006), p.43.

[6] ZHANG Sijian, YAN Luyang: Modern Machinery, vol. 36(2008), p.70.

[7] LV Sheng-lin, LIN Zi-jie: Information Technology, No. 12(2009), p.17.
