Mechanism Configuration of Super-Redundant Robot

Abstract:

Structural synthesis of super-redundant mechanism is a key to design of painting robot for S-shape duct. Based on the principles of modular structure design, the painting robot for S-shape duct falls naturally into three separate control and design components: a moving platform, a locating mechanism, and a painting manipulator. The moving platform consists of a robot body, wheels, gasbags for position adjustment, and screw jacks. The 3PR-type serial mechanism is adopted for location. The super-redundant 3P7R-type serial mechanism is used for the painting manipulator. The restriction of the distance between connecting rods and the axis of the duct is employed to control self-motion of the painting manipulator for joint trajectory planning. Experiment result shows that minimal distance between robot joints and duct interior is 18mm and that average dynamic accuracy is ±6.8mm, which satisfies the working requirements.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 68-73
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.68
• Online since: August 2013
• Authors: Yan Chen, Wen Zhuo Chen, Ken Chen, Jun Yi Shao, Wei Ming Zhang
• Keywords: Duct, Mechanism Configuration, Painting, Super-Redantant Robot

References

[1] Roh S, Choi H R: IEEE Transactions on Robotics, Vol. 21 (2005), pp.1-17.

[2] Z. Wang, H. Gu: IEEE/ASME Transactions on Mechatronics, Vol. 13 (2008), pp.383-392.

[3] J. J. Okamoto, J. C. Adamowski, et al: Mechatronics, Vol. 9 (1999), pp.731-743.

[4] Z. Song: Research on Kinematic Model and Motion Control of Wheeled Duct-cleaning Robots [D], Tsinghua University (2007). (in Chinese).

[5] H. T. Roman, B. Pellegrion: IEEE Transactions on Energy Conversion, Vol. 8 (1993), pp.576-583.

[6] J. Lim, H. Park, S. Moon, et al: Pneumatic robot based on inchworm motion for small diameter duct inspection, in Proceeding of IEEE International Conference on Robotics and Biomimetics, IEEE (2007), pp.330-335.

DOI: 10.1109/robio.2007.4522183

[7] W. Neubauer: A spider-like robot that climbs vertically in ducts, in IEEE/RSJ International Conference on Intelligent Robots and Systems, IEEE/RSJ (1994), pp.1178-1185.

DOI: 10.1109/iros.1994.407465

[8] S. Iwashina, I. Hayashi, et al: Development of in-pipe operation micro robots, in Proceeding of the International Symposium on Micromechatronics and Human Science, IEEE (1994), p.41 – 45.

DOI: 10.1109/ismmhs.1994.512896

[9] K. Liu, R. Glenntt, et al: Steward-platform-based inlet duct painting system, in Proceeding of IEEE International Conference on Robotics and Automation, IEEE (1993), pp.106-113.

DOI: 10.1109/robot.1993.291969

[10] S. M. Ryew: Induct inspection robot system with active steering mechanism, in Proceeding of IEEE International Conference on Robot System, IEEE (2000), pp.1652-1657.

[11] Y. Yang, D. Zhang, J. Wu: Machine Tool Hydraulics, Vol. 31 (2003), pp.52-54. (in Chinese).

[12] Information on https: /www. fbo. gov.
