Partially Dynamically Vulcanized Thermoplastic Elastomer Based on Natural Rubber-Polypropylene-Clay Nanocomposites

Abstract:

Thermoplastic vulcanizate (TPV) nanocomposites based on 60/40 (%wt) natural rubber (NR)/polypropylene (PP) blends were prepared by dynamic vulcanization. Sodium montmorillonite (Na-MMT) was use as a filler to improve TPV properties. The addition effect of Na-MMT on the TPV properties was examined. The results indicated that the blend exhibited a co-continuous phase structure. The presence of clay in the NR phase decreased crosslinking level of NR, but improved mixing of NR and PP during dynamic vulcanization. The addition of clay marginally enhanced the 100% modulus and tensile strength, but decreased elongation at break due to more homogeneous blend morphology. The optimal level of tensile strength improvement was obtained when loading of clay was 5 phr. The permanent set of the blends did not changed significantly with the clay dispersion. The storage modulus and resistance to oil and heat improved with incorporation of clay, proportional to clay loading.

You might also be interested in these eBooks

Multi-Functional Materials and Structures IV

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 747)

Pages:

230-233

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.747.230

Citation:

Cite this paper

Online since:

August 2013

Authors:

Natinee Lopattananon, Supattra Tanglakwaraskul, Azizon Kaesaman, Manus Seadan, Tadamoto Sakai

Keywords:

Layered Silicate, Morpholoy, Nanocomposite, Natural Rubber (NR), Polypropylene (PP)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Y. Coran, R. Patel, Rubber-Thermoplastic Combination. Part IV. Thermoplastic Vulcanizate from Various Rubber-Plastic Combinations, Rubb. Chem. Technol. 53 (1980) 141-150.

DOI: 10.5254/1.3535842

Google Scholar

[2] J. K. Mishra, G. H. Kim, I. Kim, I. J. Chung, C. S. Ha, A New Thermoplastic Vulcanizate (TPV)/Organoclay Nanocomposite: Preparation, Characterization, and Properties, J. Appl. Polym. Sci. 42 (2004) 2900-2908.

DOI: 10.1002/polb.20160

Google Scholar

[3] K. Y. Lee, L. A. Goettler, Structure-Property Relationships in Polymer Blend Nanocomposites Polym. Eng. Sci. 44 (2004) 1103-1111.

DOI: 10.1002/pen.20103

Google Scholar

[4] H. R. Dennis, D. L. Hunter, D. Chang, S. Kim, J. L. White, J. W. Cho, D. R. Paul, Effect of melt processing conditions on the extent of exfoliation in organoclay-based nancomposites, Polymer 42 (2001) 9513-9522.

DOI: 10.1016/s0032-3861(01)00473-6

Google Scholar

[5] M. Maiti, A. Bandyopadhyay, A. K. Bhowmick, Preparation and Characterization of Nanocomposites Based on Thermoplastic Elastomers from Rubber-Plastic Blends, J. Appl. Polym. Sci. 99 (2006) 1645-1656.

DOI: 10.1002/app.22699

Google Scholar

[6] M. A. Kader, K. Kim, Y. S. Lee, C. Nah, Preparation and properties of nitrile rubber/montmorillonite nanocomposites via latex blending, J. Mater. Sci. 41 (2006) 7341-7352.

DOI: 10.1007/s10853-006-0792-2

Google Scholar
