Characterizations of Mesa Structural Near-Infrared n-Type Nanocrystalline-FeSi₂/p-Type Si Heterojunction Photodiodes at Low Temperatures

Abstract:

In order to reduce the parasitic capacitance, mesa structural n-type NC-FeSi₂/p-type Si heterojunctions were fabricated by photolithography. Their current-voltage characteristics were measured in the dark and under illumination using a 1.31 μm laser in the temperature range of 60 300 K. Their junction capacitance density was evidently reduced as compared with that of the normal structural diodes. The dark current was markedly reduced with a decrease in the temperature. At 60 K, a rectifying current ratio in the dark became more than five orders of magnitude at ±1V. The ratio of the photocurrent to the dark current was dramatically enhanced to be approximately two orders of magnitude, and the detectivity was calculated to be 1.5 × 10¹¹ cmHz^1/2/W at-1V. The obtained results showed a remarkable improvement in the device performance as compared with those at 300 K.

• Periodical: Advanced Materials Research (Volume 747)
• Pages: 217-220
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.747.217
• Online since: August 2013
• Authors: Nathaporn Promros, Ryūhei Iwasaki, Suguru Funasaki, Kyohei Yamashita, Tsuyoshi Yoshitake
• Keywords: Heterojunction, Mesa Diode, Nanocrystalline FeSi₂, Photolithography, Sputtering

References

[1] X. N. Li, S. B. Li, L. F. Nie, H. Li, C. Dong, and X. Jiang, Preparation of amorphous FeSixSi(1-x) film using unbalanced magnetron sputtering, Thin Solid Films, 518 (2010) 7390 - 7393.

DOI: 10.1016/j.tsf.2010.05.014

[2] M. Milosavljevic, G. Shao, R. M. Gwilliam, Y. Gao, M. A. Lourenco, R. Valizadeh, J. S. Colligon, and K. P. Homewood, Thin Solid Films, 461 (2004) 72 - 76.

DOI: 10.1016/j.tsf.2004.02.067

[3] M. Milosavljevic, G. Shao, M. A. Lourenco, R. M. Gwilliam, K. P. Homewood, S. P. Edwards, R. Valizadeh, and J. S. Colligon, Transition from amorphous to crystalline beta phase in co-sputtered FeSi2 films as a function of temperature, J. Appl. Phys., 92 (2005).

DOI: 10.1063/1.2148629

[4] M. Milosavljevic, L. Wong, M. Lourenco, R. Valizadeh, J. Colligon, G. Shao, and K. P. Homewood, Correlation of Structural and Optical Properties of Sputtered FeSi2 Thin Films, Jpn. J. Appl. Phys., 49 (2010) 081401 - 081401-4.

DOI: 10.1143/jjap.49.081401

[5] T. Yoshitake, M. Yatabe, M. Itakura, N. Kuwano, Y. Tomokiyo, and K. Nagayama, Semiconducting nanocrystalline iron disilicide thin films prepared by pulsed-laser ablation, Appl. Phys. Lett., 83 (2003) 3057 - 3059.

DOI: 10.1063/1.1617374

[6] N. Promros, K. Yamashita, C. Li, K. Kawai, and M. Shaban, n-Type Nanocrystalline FeSi2/intrinsic Si/p-Type Si heterojunction Photodiodes Fabricated by Facing-Target Direct-Current Sputtering, Jpn. J. Appl. Phys., 51 (2012) 021301 - 021301-4.

DOI: 10.7567/jjap.51.021301

[7] K. Takarabe, H. Doi, Y. Mori, K. Fukui, Y. Shim, N. Yamamoto, T. Yoshitake, and K. Nagayama, Optical properties of nanocrystalline FeSi2 and the effects of hydrogenation, Appl. Phys. Lett., 88 (2006) 061911 - 061911-3.

DOI: 10.1063/1.2172711

[8] S. Nakamura, T. Aoki, T. Kittaka, R. Hakamata, H. Tabuchi, S. Kunitsugu, and K. Takarabe, Facing target sputtered iron-silicide thin film, Thin Solid Films, 515 (2007) 8205 - 8209.

DOI: 10.1016/j.tsf.2007.02.038

[9] M. Shaban, H. Kondo, K. Nakashima, and T. Yoshitake, Electrical and Photovoltaic Properties of n-Type Nanocrystalline-FeSi2/p-Type Si heterojunctions Prepared by Facing-Targets Direct-Current Sputtering at Room Temperature, J. Appl. Phys., 47 (2008).

DOI: 10.1143/jjap.47.5420

[10] M. Shaban, K. Kawai, N. Promros, and T. Yoshitake, n-Type Nanocrystalline-FeSi2/p-Type Si Heterojunction Photodiodes Prepared at Room Temperature, IEEE Electron Device Letter, 31 (2010) 1428 - 1430.

DOI: 10.1109/led.2010.2078793

[11] M. Shaban, S. Izumi, K. Nomoto, and T. Yoshitake, n-type β-FeSi2/intrinsic-Si/p-type Si heterojunction photodiodes for near-infrared light detection at room temperature, Appl. Phys. Lett., 95 (2009) 162102 - 162102-3.

DOI: 10.1063/1.3250171

[12] S. Izumi, M. Shaban, N. Promros, K. nomoto and T. Yoshitake, Near-infrared photodetection of –FeSi2/Si heterojunction photodiodes at low temperatures, Appl. Phys. Lett., 102 (2013) 032107 - 032107-4.

DOI: 10.1063/1.4789391

[13] N. Promros, K. Yamashita, S. Izumi, R. Iwasaki, M. Shaban and T. Yoshitake, Near-Infrared Photodetection of n-Type β-FeSi2/Intrinsic Si/p-Type Si Heterojunctions at Low Temperatures, Jpn. J. Appl. Phys., 51 (2012) 09MF02 - 09MF02-4.

DOI: 10.7567/jjap.51.09mf02

[14] N. Promros, K. Yamashita, R. Iwasaki, and T. Yoshitake, Effect of Hydrogen Passivation on Near-Infrared Photodetection of n-Type β-FeSi2/p-Type Si Heterojunction Photodiodes, Jpn. J. Appl. Phys., 51 (2012) 108006-108006-2.

DOI: 10.7567/jjap.51.108006
