Stochastic First-Ply Failure Analysis of Laminated Composite Plates under in Plane Tensile Loading

Abstract:

The present work deals with second order statistics of first-ply failure response of geometrically nonlinear laminated composite plate subjected to in-plane tensile loading with random system properties. System properties such as the material properties and lamina plate thickness are modeled as independent random variables.The mathematical formulation is based on higher order shear deformation theory (HSDT) with von-Karman nonlinear kinematics. An efficient C⁰ nonlinear finite element method based on direct iterative procedure in conjunction with a first order perturbation approach (FOPT) is extended successfully and applied for failure problem in random environment and is employed to evaluate the dimensionless mean failure load and variance of failure index by modeling the system properties as basic random variables using Tsai-Wu and Hoffman failure criteria.Typical numerical results are presented to examine the effect of amplitude ratios, boundary conditions, lamination schemes with random system properties for different failure criterion.The results obtained using present solution approach is validated with the results available in the literatures.

You might also be interested in these eBooks

Multi-Functional Materials and Structures IV

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 747)

Pages:

269-272

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.747.269

Citation:

Cite this paper

Online since:

August 2013

Authors:

Appaso M. Gadade, Achchhe Lal, B.N. Singh

Keywords:

First-Ply Failure Loads, Laminated Composite Plate, Random System Properties, Stochastic Finite Element Method

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Lal Achchhe, Singh B.N., Patel Dipan. Stochastic nonlinear failure analysis of laminated composite plate under compressive transeverse loading. Composite Structures, 94 (2012), 1211–1223.

DOI: 10.1016/j.compstruct.2011.11.018

Google Scholar

[2] Reddy Y. S. N. & Reddy J. N., Linear and non-linear failure analysis of composite laminates with transverse shear, Composites Science and Technology 44 (1992), 227-255.

DOI: 10.1016/0266-3538(92)90015-u

Google Scholar

[3] Onkar AK, Upadhyay CS, Yadav D. Probabilistic failure of laminated composite plates using the stochastic finite element method. Compos. Struct. 2007; 77(1): 79–91.

DOI: 10.1016/j.compstruct.2005.06.006

Google Scholar

[4] Kam TY, Lin SC, Hsiao KM. Reliability analysis of nonlinear laminated composite plate structures. Compos. Struct. 1993; 25(1–4): 503–10.

DOI: 10.1016/0263-8223(93)90198-y

Google Scholar
