The Analysis of Feeding Crossbeam on the Automatic Aluminous-Winding Machine

Abstract:

The feeding crossbeam on the automatic aluminous-winding machine plays a supporting role in the preparation process of feeding pipe, the deformation of the feeding crossbeam have a direct impact on mechanical accuracy, it is difficult problem in model design, which is how to design a reasonable structure and make the crossbeam meets the requirements of strength and stiffness, as well achieve lightweight design. This article considers the complex force of crossbeam, and bases on the principle of virtual work and finite element theory, using ANASYS software to make a finite element model, the relation curves of the stress and the strain under the maximum load are summarized and the stress concentration area is found, The current study provides more reliable results to improve design.

• Periodical: Advanced Materials Research (Volume 748)
• Pages: 336-340
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.748.336
• Online since: August 2013
• Authors: Yi Hua Zhang, Pei Hai Hou, Tie Qun Duan, Yuan Gao, Hui Min Han, Zhen Qi Yang
• Keywords: ANASYS, Crossbeam, Finite Element Analysis (FEA), Optimization Design

References

[1] Zhilun Xu. Concise Textbook of Elasticity. Beijing: Higher Education Press, (2002).

[2] Ping'an Du, Ezhong Gan, Yating Yu. Finite Element Method: theory, Beijing: model and application. National Defense Industry Press, (2004).

[3] Jiujiang Zhao, Shaoshi Zhang, Chunxiang Wang. Mechanics of materials. Harbin: Harbin Institute of Technology press, (2000).

[4] Renxi Hu, Qingwu Wang, Shi Yan. ANASYS8. 2 Mechanical Design Senior Application Examples. Beijing: Machinery Industry Press, (2005).
