Airborne Integrated Vision/Inertial Navigation System for Landing on Aircraft Carrier

Abstract:

It is a very difficult task to land on aircraft carrier, because of limits of the carrier runway during rough sea. In this article, a new algorithm of aircraft carrier landing is proposed utilizing airborne infrared camera/inertial integrated system, which can provide the relative positions and orientation of the aircraft with respect to the carrier so as to help aircrafts semi-auto or auto landing. The mathematic relationship between guidance parameters and imaging information was modeled, and then the relative position and attitude information between the carrier and the aircraft were estimated through Newton iteration method. From that information, the pitching, rolling and heave movement of the carrier were estimated and compensated, so the touchdown point could be predicted and provided to the pilot so as to control aircraft landing. On the ground of the theoretic research, the field verification tests were carried out, which adopted the minification scheme to simulate the process of aircraft carrier landing. In the experiments, the runway simulator simulated the motion of the carrier runway and the land vehicle was used as the aircraft. The results verify the landing guidance system scheme is feasible and effective, and lay the technical foundation for the flight test, improving its safety.

• Periodical: Advanced Materials Research (Volume 748)
• Pages: 747-753
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.748.747
• Online since: August 2013
• Authors: Dan Wang, Wei Wang
• Keywords: Aircraft Carried, Approach Landing, Field Test, Inertial Navigation System (INS), Infrared Camera

References

[1] C. Sharp, O. Shakernia, and S. Sastry: IEEE International Conference on Robotics and Automation, Vol. 2(2001).

[2] O. Yakimenko, I. Kaminer, W. Lentz, and P. Ghyzel: IEEE Transactions on Aerospace and Electronic Systems, Vol. 38(2002), p.1181.

DOI: 10.1109/taes.2002.1145742

[3] T. Gonc¸alves, J. Azinheira, and P. Rives: International Conference on Informatics in Control, Automation and Robotics(2009).

[4] Hong-xiang J, Jin-fa X, Zheng G: Acta Aeronautica Et Astronautica Sinica, Vol. 31( 2010), p.744.

[5] L. Coutard and F. Chaumette: IEEE Int. Conf. on Robotics and Automation(China 2011).

[6] S Joo, C Ippolito, K Al-Ali, et al: IEEE Aerospace Conference, Big Sky(Montana 2008), p.1.

[7] W Ba-gen, H Ji-zhong, X Yuan-ming: Journal of Beijing University of Aeronautics and Astronautics, Vol. 36(2010), p.986.
