Study on Temperature and High Cycle Fatigue Evaluation of Heavy Duty Diesel Engine Cylinder Head and Improved Design

Abstract:

A synthesized simulation process was used to predicting temperature and high cycle fatigue (HCF) of cylinder head in this paper. Firstly, the temperature prediction model was built and calibrated by the test data, which ensured the rationality. The simulation result shows that the material thermal conductivity is very low and the position of the drilling holes near the deck is very high, and the thermal load was reduced effectively through improving the material conductivity and optimizing the structure design. Finally a fatigue life evaluation has been performed which shows the HCF safety factor is higher than the original design due to the temperature reduction.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 1044-1049
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.1044
• Online since: August 2013
• Authors: Guo Xi Jing, Ru Hua Zhang, Chang Min Guo, Peng Li, Xiu Qiao Wang
• Keywords: Cylinder Head, Diesel Engine, Finite Element Method (FEM), Thermal Load

References

[1] Thomas Hamm, Martin Rebbert, Hermann-Josef Ecker, et al. Cylinder Head Design for High Peak Firing Pressures[C]. SAE Paper 2008-01-1196.

DOI: 10.4271/2008-01-1196

[2] Md. Hazrat Ali, Masjuki Hassan, Md. Kalmar, et al. Determination of Time Variant 1D-3D Temperature and Heat Transfer Distribution Inside the Cooling Jacket of a SI Engine Cooling System after Key-Off[C]. SAE Paper 2012-01-0642.

DOI: 10.4271/2012-01-0642

[3] Zhang Wei-zheng, Liu Jin-xiang, Wei Chun-yuan. Main Cause of Thermal Stress and Sloving Methods for Heated Components of Engine [J]. Internal combustion engine engineering, 2003(2), 5~8.

[4] Xiao Yong-ning, Pan Ke-yu, Han Guo-yan. Heat load and heat intensity of Internal combustion engine[M]. BeiJing: Mechanical Industry Press, (1998).

[5] Dai Guo-sheng. Heat transfer theory [M]. BeiJing: Higher Education Press, (1999).
