Study on 3D Model of Square Dome Shaped Pipe Based on AutoCAD

Abstract:

Two kinds of 3D modeling methods for square dome shaped pipe (SDSP) are presented in this paper, i.e. Manual modeling method by means of relative commands provided by AutoCAD and automatic modeling method by means of AutoLISP programming. The modeling steps are described in detail in the manual modeling method. Based on these, the 3D modeling application for SDSP is developed by means of AutoLISP language. The parameterized modeling of SDSP is achieved, and the drawing efficiency is increased effectively.
