Impact of Temperature Control on the Dynamic Clearance of the Injection System of Squeeze Casting Machine

Abstract:

Changes of the clearance between punch and chamber resulting from thermal-mechanical loading effects affect the injection process of squeeze casting greatly. This paper aims to control the changes of the dynamic clearance in order to ensure the smooth operation of the injection system. A temperature control method by cooling punch was proposed, and two cases of vertical injection processes, which were cooling and non-cooling, were simulated during the ten squeeze casting cycles. The clearance changed from the initial 0.15mm to the stable 0.099mm in the case of cooling, while from the initial 0.15mm to the stable 0.071mm in the case of non-cooling, which demonstrated the temperature control method was effective and feasible.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 1396-1400
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.1396
• Online since: August 2013
• Authors: Shang Ping Bai, Dong Dong You, Jia Huan Zhao, Yuan Yuan Li
• Keywords: Dynamic Clearance, Injection System, Squeeze Casting, Temperature Control

References

[1] M Zhang, W W Zhang, H D Zhao. Transactions of Nonferrous Metals Society of China Vol. 17 (2007), pp.496-501.

[2] Shoujing Luo, Jufu Jiang, Ying Wang: Transactions of Nonferrous Metals Society of China Vol. 13 (2003), pp.370-375.

[3] Jianxin Deng, ming Shao, Dongdong You: Foundry Vol. 57 (2008), pp.643-646.

[4] Maoliang Hu, Mi Zhao, Zesheng Ji: Special Casting and Nonferrous Alloys Vol. 25 (2005), pp.155-157.

[5] Shi Qi. Prediction of thermal distortion and thermal fatigue in shot sleeves. Ph.D. Thesis, Columbus: The Ohio State University, (2002).

[6] Xinping Hu, Guoqun Zhao, Bingyao Wu: China Foundry Vol. 5 (2008), pp.47-53.

[7] Shangping Bai, Dongdong You, Yuanyuan Li. Special Casting and Nonferrous Alloys Vol. 32 (2012), pp.740-743.

[8] Ri Li, Fei Li, Jianqiang Zhang. Study on boundary search method for DFM mesh generation. China Foundry Vol. 9 (2012), pp.231-233.

[9] Ri Li, Junxian Ma, Qiyu Cui. Casting process simulation ProCAST from the entry to the proficient. Bei Jing: China Water Power Press, (2010).

[10] Chaozhong Wu. Investigation of the interface heat transfer coefficients of aluminum squeeze castings. Master's Thesis, Guang Zhou: South China University of Technology, (2011).

[11] Yunqi Liang. Heat transfer and thermal deformation foundation of the machinery manufacture. Bei Jing: Machinery Industry Press, (1982).
