Single Neuron PID Control of a Turbofan Engine with Inlet Pressure Distortion

Abstract:

In this paper, a preliminary exploration and research about the adaptive control law has been carried on for the turbofan engine with inlet pressure distortion. First, a real-time dynamic component-based model which contains the inlet distortion effects was established. Then, we select a single neuron PID controller with adaptive parameters to complete the dynamic acceleration process. The results illustrate that the single neuron control algorithm with gain adaptive has strong robustness, self-learning and anti-jamming capability and the performance of a turbofan engine can be effectively improved by using the turbine expansion ratio adaptive control law.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 1534-1538
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.1534
• Online since: August 2013
• Authors: Bin Wang*, Xi Wang, Yue Liu
• Keywords: Distortion Tolerance Control, Pressure Distortion, Single Neuron PID, Turbine Expansion Ratio, Turbofan Engine

References

[1] Graber E J, Braithwaite, W M, Summary of recent investigations of inlet flow distortion effects on engine stability [R], AIAA pp.74-236.

DOI: 10.2514/6.1974-236

[2] Braithwaite, W M, Soeder R H, Combined pressure and temperature distortion effects on internal flow of a turbofan engine[R], AIAA pp.79-1309.

DOI: 10.2514/6.1979-1309

[3] SAE Aerospace Information Repeat, Inlet total-pressure-distortion considerations for gas turbine engine[s], Society of Automotive Engineer, AIR1419, (1983).

[4] Tian Dexin, Liu Yanheng, LI bin, Wu Jing, Distributed Neural Network Learning Algorithm Based on Hebb Rule[J], Chinese Journal of Computers, 2007, 30(08): pp.1381-1385. (In Chinese).

[5] Yu Lei，He Xiaoyang, Liu tao, On Single Neural PID Controller with Gain Self-Adaptive[J], Journal of Hunan University Technology, 2007, 21(05): pp.45-47. (In Chinese).

[6] Cheng Bangqin, Wang Xu, Tao Zengyuan, Effect of Inlet Pressure Distortion on the Performance of a Certain-type Turbofan Engine, Journal of Air Force Engineering University(Natural Edition). 2004, (04), pp.4-7. (In Chinese).

[7] Sun Peng, Feng Guotai, Kui Dongwei, Numerical Simulation of the Impact of Total-pressure Distortion on the Aerodynamic Performance of Small-sized Fans[J], Journal of Engineering for Thermal Energy and Power, 2006, 21(3), pp.260-263. (In Chinese).

[8] Yu Longjiang，Piao Ying, Full range modeling of aero engine systems based on a simplified algorithm[J], Journal of Aerospace Power, 2008, 23(03): pp.511-515. (In Chinese).

[9] Kim J H, Song T W, Kim T S, et al, Model development and simulation of transient behavior of heavy duty gas turbine[J], Journal of Engineering for Gas Turbine and Power, 2001, 12(3): pp.589-594.

DOI: 10.1115/1.1370973

[10] H. Austin Spang III, Harold Brown, Control of jet engines[J], Control of Engineering for Practice Turbine and Power, 1999, 7: pp.1043-1059.

DOI: 10.1016/s0967-0661(99)00078-7
