Applying Wireless Transmission for Aluminum Alloy Wheel Cornering Simulation and Testing

Abstract:

This study adopted finite element analysis (FEA) to conduct tests and simulations on the bending moment of truck wheels. Based on the simulated analysis using ANSYS Workbench software, a three-axis strain gauge was attached to locations with substantial stress variations. The strain gauge was converted into voltage. Amplification and filtering circuits were adopted for signal processing, and the processed signals were subsequently entered into the microcontroller unit. Simultaneously, a universal asynchronous receiver/transmitter (UART) communications protocol was applied for communication with the Bluetooth wireless module. The accessed signal was then transmitted to the receiver end through wireless emission. The detection interface at the monitoring end was designed using LabVIEW software, enabling operators to observe the stress and strain for wheels under various test conditions. The acquired data were stored in a computer for future reviews and analysis.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 2383-2389
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.2383
• Online since: August 2013
• Authors: San Shan Hung, Hsing Cheng Chang, Yu Hsuan Lin
• Keywords: Cornering Bending Test, Strain Gauge, Truck Wheel

References

[1] U. Kocabicak and M. Firat: Engineering Failure Analysis, Vol. 8 (2001) No. 4, p.339.

[2] P. Ramamurty Raju, B. Satyanarayana, K. Ramji, K. Suresh Babu: Engineering Failure Analysis, Vol. 4 (2007) No. 5, p.791.

[3] Mehmet Firat, Recep Kozan, Murat Ozsoy and O. Hamdi Mete: Engineering Failure Analysis, Vol. 16 (2009) No. 5, p.1533.

[4] Sheng Zan Yan: Finite Element Analysis and Experiment Study on Aluminum Alloy Wheel Structure (Ph.D., Zhejiang University, China 2008).

[5] Information: http: /www. artc. org. tw/chinese/03_service/03_02detail. aspx?pid=1693.

[6] Xiaofeng Wang and Xiaoge Zhang: International Journal of Fatigue, Vol. 32 (2010) No. 2, p.434.

[7] J. W. Dally, W. F. Riley and K. G. McConnell: Instrumentation for Engineering Measurements (John Wiley and Sons Inc., America 1984).

[8] Rui Hong Zhi: Mechanical Management And Development, Vol. 24 (2009) No. 6.

[9] Chun Ming Kuo, Yuan Fu Lin, Yu Cheng Lin and Yu Jen Hsu: Society of Theoretical and Applied Mechanics of the Republic of China (Taiwan, December 2006).

[10] Yuan Chun Li: ANSYS Workbench Design Modeler and Simulation (Publishing House of Electronics Industry, China2011).

[11] Ping Li, Cheng Chia Ho and Hsueh Feng Chen: ANSYS Workbench Design, Simulation and Optimization (National Tsing Hua University Press, China 2011).

[12] L. Wang, Y. Chen, C. Wang and Q. Wang: Journal of Mechanical Engineering, Vol. 57 (2011) No. 3, p.31.

[13] G. Wang, H. Sun, J. Li and Y. Wang: Control and Decision Conference 2009, (China, June 17-19, 2009). p.3448.
