Application of Controller with Complex Zeros in the Photoelectric Tracking System

Abstract:

In the photoelectric imaging tracking system with the low frame-frequency CCD, low sampling frequency and delay in the system restrain the closed-loop bandwidth and the tracking precision of the system. In general, the zeros-poles cancellation method is employed in this system to cure for resonance and broaden the bandwidth of the system, but the method depends on the precise mathematical model and relatively higher sampling frequencies. In this paper, a PID controller with complex zeros is proposed and analyzed, which is applied to the FSM system based on the low frame-frequency CCD; next, good closed-loop performance obtained through the controller is presented. It is found from many experiments that zeros-poles cancellation cannot be applied to the tracking system with low sampling frequency without other assistant methods, which may not be required in the new method. Finally, the CCD with a frequency of 200Hz is used in the FSM tracking experiment to verify the method, and the experiment result shows that the performance of the system achieved by means of the novel controller can meet the design requirements.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 673-677
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.673
• Online since: September 2013
• Authors: Jiang Ming Kuang, Shuang Zhang
• Keywords: Bandwidth, Complex Zeros, Delay, Fast Steering Mirror, Low Sampling Frequency

References

[1] Tang Tao, Huang Yongmei, Fu Chengyu and Liu Shunfa, Acceleration feedback of a CCD-based tracking loop for fast steering mirror [J], Optical Engineering, Vol. 48, No. 1, 1-6(2009).

DOI: 10.1117/1.3065500

[2] Fu Chengyu, Jiang Lingtao, Ren Ge and Ma Jiaguang, Experiment system of fast steering mirror [J], Opto-Electronic Engineering (in Chinese), Vol. 21, No. 3, 1-8(1994).

[3] Fu Chengyu, Ma Jiaguang, Ye Buxia, Wang Hongman and Huang Yongmei, The Application Research of the Composite Axis Control System [J], Opto-Electronic Engineering (in Chinese), Vol. 21, No. 4, 1-12(1998).

[4] Francisc M. Tapos, Derek J. Edinger, Timothy R. Hilby, Melvin S. Ni, Buck C. Holmes, David M. Stubbs, High bandwidth fast steering mirror [J], Proceedings of SPIE Vol. 5877 (SPIE, Bellingham, WA, 2005).

DOI: 10.1117/12.617960

[5] Wu Qiongyan, Wang Qiang, Peng Qi, Ren Ge and Fu Chengyu, Wide bandwidth control of a fast-steering-mirror driven by voice coil motor [J], Opto-Electronic Engineering (in Chinese), Vol. 31, No. 8, 15-18(2004).

[6] Wang Qiang, Chen Ke, Fu Chengyu, Method for controlling fast-steering mirror driven by voice coil motor based on the closed-loop performance [J], Opto-Electronic Engineering (in Chinese), Vol. 32, No. 2, 9-12(2005).

[7] Ma Jiaguang, The Basic Technologies of the Acquisition, Tracking and Pointing systems [J], Optic Engineering (in Chinese), Vol. 15, No. 3, 1-40(1989).

[8] Chodos Steven L. Track loop bandwidth, sensor sample frequency, and track loop delays [J], Proc. SPIE 3365, 69-76(1998).

DOI: 10.1117/12.317531

[9] Ellis George, Control System Design Guide [M], Publishing House of Electronics industry, Beijing, 258-272(2004).

[10] Zhang Yong, Wu Qinzhang, Research on adaptive Kalman filtering based on interacting multiple model [J], Proc. of SPIE Vol. 6833, 683324, (2007).

[11] Lin Gao, Peng Tang, Zhifang Liu, Real time object tracking using adaptive kalman particle filter [J], Proc. of SPIE Vol. 6786, 67863O, (2007).

[12] N´estor O. P´erez Arancibia, Steve Gibson and Tsu-Chin Tsao, Saturation and Frequency Weighting in Adaptive Control of Laser Beam Jitter [J], Proc. of SPIE Vol. 6709, 67090Q, (2007).

DOI: 10.1117/12.737336

[13] N´estor O. P´erez Arancibia, Neil Chen, Steve Gibson and Tsu-Chin Tsao, Adaptive Control of Jitter in Laser Beam Pointing and Tracking [J], Proc. of SPIE Vol. 6304, 63041G, (2006).

DOI: 10.1109/acc.2006.1656631

[14] A. Sinha, T. Kirubarajan and Y. Bar-Shalom, Application of the Kalman-Levy Filter for Tracking Maneuvering Targets [J], Proceedings of SPIE Vol. 5428 (SPIE, Bellingham, WA, 2004).

DOI: 10.1117/12.542896
