Finishing Characteristics in Barrel Finishing of Centrifugal Disc Type on Flow-Through System

Abstract:

For the improvement of the performance in centrifugal disc finishing, the flow-through system for supplying the compound solution is tried and its influences on finishing characteristics are experimentally investigated. Workpieces (22 mm in diameter and 15 mm in thickness) of plain carbon steel (S45C in JIS), aluminum alloy (A2017) and copper alloy (C3604) are finished with ceramic media (Equilateral triangular prism 6 mm in side and 5 mm in thickness). The conclusions are summarized as follows; The compound solution has more influences on finishing characteristics than plain water. It makes the relative stock removal larger and the surface roughness smaller than the water. The relative stock removal and the media weight loss on the flow-through system are larger than those on the batch system.

• Periodical: Advanced Materials Research (Volumes 76-78)
• Pages: 300-305
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.76-78.300
• Online since: June 2009
• Authors: Koichi Kitajima, Akihiro Yamamoto, Shinji Takahashi, Masatomo Watanabe
• Keywords: Barrel Finishing , Centrifugal Disc Type, Compound, Flow-Through System, Mass Finishing, Media Weight Loss, Stock Removal, Surface Roughness (SR)

References

[1] L. K. Gillespie: Mass Finishing Handbook, Industrial Press. New York (2007), p.147.

[2] T. Ishida, S. Yoshida, Y. Kono and M. Hiraga: Shinto Tech. Rep. No. 14 (1994), p.39 (in Japanese) 0.

2.

4.

6.

8 200 [ml/min] 600 [ml/min] 10 [l/batch] Flow rate of water Surface roughness [umRa] S45C A2017 C3604 0.

2.

4.

6.

8 200 [ml/min] 600 [ml/min] 10 [l/batch] Flow rate of solution Surface roughness [umRa] S45C A2017 C3604 60min 60min Surface roughness [umRa] Surface roughness [umRa].
