Comparison of Design and Spatial Stability of Two Kinds of Optical Systems for Stereoscopic Mapping Camera

Abstract:

To achieve a certain precision when mapping in accord with a particular proportion or scale with stereo mapping camera, the change of chief ray height of the edge field due to the fluctuation of working temperature is required to be within the range of microns, and at the meantime the size and structure layout of three-linear array stereo mapping camera are determined directly by the configuration of optical system. Based on the requirements of refractive optical system with long focal length, academic calculation and actual optical designs based on two typical configurations for stereoscopic mapping camera are made,the actual working temperature and performance requirements are also taken into consideration, the results including the modulation transfer function, distortion and stability comparison are also given.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 368-372
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.368
• Online since: September 2013
• Authors: Tian Jin Tang, Wei Jun Gao
• Keywords: Configurations, Distortion, Stability, Stereo Mapping Camera

References

[1] Xinming Tang, Nan Cong, Present Situation and Development of Surveying and Mapping Satellites in China, Science of Surveying and Mapping, Volume 34(2009), p.40, In Chinese.

[2] Renxiang Wang, mapping satellite without control point in china, Hydrographic Surveying and Charting, Volume 28(2008), p.1, In Chinese.

[3] Kidger, M: Fundamental Optical Design. SPIE Press, Bellingham, WA.

[4] Daoyin Yu: Physical Optics(Zhejiang University publishing company, HangZhou 2002).

[5] Optical Design Program User's Guide(ZEMAX Development Corporation, 2005).
