A New Two-Dimensional Photonic Crystal Channel Drop Filter Based on Two-Resonant Cavities

Abstract:

In this paper, a channel drop filter (CDF) is composed of two cubic lattice circular ring resonator cavities and point micro-cavities in a two-dimensional photonic crystal. The photonic band gap is calculated using the plane wave expansion (PWE) method and the optical characteristics of proposed structure are studying by the finite difference time domain (FDTD) method with perfectly matched layers (PMLs) acting as the boundary conditions . Two different wavelengths centered at 1773 nm and 1742 nm have been successful separation in this CDF. These demonstrate that our proposed structure is suitable for photonic integrated circuits (PICs) and coarse wavelength division multiplexing (WDM) optical communication systems.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 397-400
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.397
• Online since: September 2013
• Authors: Ying Hu, Gui Qiang Liu, Xiang Nan Zhang, Zheng Jie Cai
• Keywords: Channel Drop Filters, Photonic Crystal (PC), Point Micro-Cavities, Ring Resonators

References

[1] E. Yablonovitch: Phys. Rev. Lett. Vol. 58 (1987), p. (2059).

[2] S. John: Phys. Rev. lett. Vol. 58 (1987), p.2486.

[3] G.Q. Liu, H.H. Hu, Y.B. Liao, Z.S. Wang, Y. Chen, and Z.M. Liu: Optik. Vol. 122 (2011), p.9.

[4] Z.Q. Liu, T.H. Feng, Q.F. Dai, L.J. Wu, and S. Lan: Chinese. Phys. B. Vol. 18 (2009), p.2383.

[5] L.T. Song, J. Hu, and H.L. Wang: Chinese.J. Lasers. Vol. 37(2010), p.2834.

[6] N.D. Cui, J.Q. Liang, and Z.Z. Liang: Acta Optica Sinica. Vol. 32(2012).

[7] F. Monifi, A. Ghaffari, M. Djavid, and M.S. Abrishamian: Appl. Opt. Vol. 48 (2009), p.804.

DOI: 10.1364/ao.48.000804

[8] X. Hu, Q. Gong, S. Feng, B. Cheng, and D. Zhang: Opt. Commun. Vol. 253 (2005), p.138.

[9] D.M. Pustai, A. Sharkawy, S. Shi, and D.W. Prather: Appl. Opt. Vol. 41 (2002), p.5574.
