Modeling and Analysis of Grid-Connected Inverter for PV Generation

Abstract:

In order to improve the efficiency of photovoltaic generation as well as the power quality, grid-connected inverters for PV generation research was carried out for photovoltaic maximum power point tracking. Based on some current studies on the incremental conductance method, an advanced incremental conductance control algorithm was proposed, which can track maximum power point rapidly and accurately. The oscillation phenomenon, which exists near the maximum power point, was improved at a great extent, so to the efficiency of photovoltaic cells generation electricity. The inverter control system has an advantage in its high speed and flexibility by applying advanced control algorithm. And the source harmonic current is remarkably reduced. In addition, the power factor is enhanced and the power quality is improved. Finally, according to the principle of inverter control system and based on the analysis on the mathematical model of photovoltaic inverter, a simulation model of that is established based on MATLAB/SIMULINK.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 451-456
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.451
• Online since: September 2013
• Authors: Neng Cao, Ya Jun Cao, Jiao Yu Liu
• Keywords: Grid Connected, Incremental Conductance Method, Inverter, MATLAB, MPPT, PV

References

[1] C. H. Wu, The Research of Inverter for PV Generation, Shanghai: Shanghai University, (2008).

[2] X. Zou, and L. Z. YI, Constant-frequency Hysteresis Current Control of PV grid-connected Inverter, Electric Power Automation Equipment, 2008, 4(28), pp.58-62.

[3] L. Pan, Photovoltaic inverter design and control, Energy and Energy Efficiency, 2011, p.83–85.

[4] W. D. Wang, Z.K. Wen, Matlab Simulation of Photovoltaic Arrays, Electroinc Components & Device Applications, 2010, 12(9), pp.89-90.

[5] Z. J. Tang, C. L. Wang, X. F. Fang, MPPT Implementation Strtegy Based on the Conductance Increment Method, Power Electronics, 2011, 45(4), pp.73-75.

[6] X. Y. Li, X. Wang, F. Zheng, The MPPT Improved Algorithm and Simulation under Changing Irradiance of Grid-Connected PV Systems, Energy Technology, 2009, 30(5), pp.272-279.

[7] H. Z. Yang and X. M. Jin, Research on Grid-Connected Photovoltaic Inverter of Maximum Power Point Tracking, The University of Traffic, 2004, 28(2), pp.65-68.
