The Vibration Modal Testing and Analysis of an Experiment Gun Mount

Abstract:

An experiment gun mount system is used to clamp the small arms and replace gunner to conduct the automatic shooting in the shooting accuracy test. Because of the concomitant phenomena such as high shock and vibration when shooting, to study the vibration characteristics of the system, a modal analysis method was proposed and the experimental points, including the exciting points and the vibration pickup points, were determined on the basis of its geometric model. Based on the Fast Fourier Transform technique, the CRAS modal testing system was built. The modal experiment of the system was carried out by hammer blow method. The exciting signals, spectra of impacting prompt power, vibration acceleration and their frequency response functions were obtained. The first six order vibration modes, damping ratio and the corresponding vibration frequencies were obtained, which laid the foundation for dynamic response calculation and further optimization design of the system in the future.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 938-941
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.938
• Online since: September 2013
• Authors: Lei He, Jian Zhang, Ke Dong Zhou, Peng Han Gong
• Keywords: Modal Analysis, Natural Characteristics, Testing Gun Mount, Vibration Test

References

[1] Wang Rui-lin. The Researches on Dynamic Characteristics and Firing Accuracy of Large Caliber Machine Gun[D]. Ph.D. Dissertation. Nanjing University of Science and Technology, (2003).

[2] Zhao Meng, Zhang Yi-du, Ma Liang-wen, Zhao Li-li. Research on Modal Analysis of Assembly Structures based on Msc/Nastran[J]. Vibration and Shock, 2005, 24(1): 28-30.

[3] Berman. M. Advanced Gun System Dynamic Characterization: Model Test and Analysis, High Frequency Analysis, 1999, 12.

[4] Hopkins, D. A. Modeling Gun Dynamics with Three-Dimensional Beam Elements. 1990, 11, 229~277.

[5] Wardour H, Steven L, Bohr S. Modal analysis theory and experiment[M]. Beijing: Beijing Institute of Technology Press, (2001).

[6] Xu Cheng, Wang Ya-ping. Dynamics of cannon and Automatic Weapons[M]. Beijing: The publishing House of Beijing University of Science and Technology, (2006).

[7] He Lei, Wang Jin, Guan Hong-gen, Zhou Ke-dong. Application and practice of modal experiment analysis in teaching[J]. Experimental Technology and Management, 28(5), 133-136.
