Implementation of a Low Cost Resonant Boost Converter Connected Photo Voltaic System

Abstract:

This paper proposes a hardware implementation of a resonant boost converter with photovoltaic system. The converter finds varied advantages like lower switching losses and increased efficiency. With the increased rate of energy crisis, the converter has paved a new way for solving the problem, in the recent years. The dc voltage source of the resonant boost converter is replaced by a photovoltaic system that energizes the converter. The renewable energy minimizes the fuel cost and highly decreases the maintenance cost. A PIC microcontroller is used to generate the pulses of the transistor switches in the boost converter and for the inverter circuit. Implementation of a low cost 16F877A microcontroller with a resonant boost photo voltaic system with higher efficiency and the experimental results has been tabulated. The performance of the circuit has been verified at different temperatures for different applications.

• Periodical: Advanced Materials Research (Volume 768)
• Pages: 80-83
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.768.80
• Online since: September 2013
• Authors: R.C. Ilambirai, Rajesh Boga
• Keywords: Inverter, Photovoltaic (PV) Array, PIC Microcontroller, Resonant Boost Converter

References

[1] Pourya Shamsi, Babak Fashimi, Design and development of very high frequency resonant DC-DC resonant boost converter, IEEE Trans. Power electron , vol. 27, No. 8, AUGUST 2012, Pg no: 3275-3733.

DOI: 10.1109/tpel.2012.2185518

[2] J. C, Rosas-Caro,J. M Ramirez,F. Z Peng A. Valderrabano A DC-DC Multi level boostconverter, IETPowerElectron, 2010, Vol. 3. lss. 1, Pg no: 129-137.

[3] Jang, Ahmed Hassan, Load current based analog MPPT Controller for PV solar systems, 2012, IEEE, Pg. No. 911-914.

[4] Yuncong Jiang, Ahmed Hassan, Load current based analog MPPT Controller for PV solar systems, 2012, IEEE, Pg. No. 911-914.

[5] H. Jiar, S. Mansourpor, E. Afjei, Detecting harmful over currents in PV arrays in shadowing conditions through binary coding method, 2012, IEEE, Pg. No 251-254.

[6] Zhigang Liang, Alex Q. Huang, Rong Guo, member IEEE High efficiency Switched capacitor Buck. Boost converter for PV Cell, IEEE trans@2012, Pg no: 1951-195.

DOI: 10.1109/apec.2012.6166090

[7] Morten Nymand and Michel A. E. Andersen, High-efficiency isolated boost DC-DC converter for high-power low-voltage fuel-cell applications, IEEE Trans. Ind. Electron., vol. 57, no. 2, pp.505-514, Feb. (2010).

DOI: 10.1109/tie.2009.2036024

[8] Bo Yuan, Xu Yang, and Donghao Li, A step-up DC-DC converter with a resonant voltage doubler, IEEE Trans. Ind. Electron., vol. 54, no. 6, pp.3267-3275, Dec. 2007.

DOI: 10.1109/tie.2007.906174

[9] R. Pilawa-Podgurski, A. Sagneri, J. Rivas, D. Anderson, and D. Perreault, Very-high-frequency resonant boost converters, IEEE Trans. Pow. Electron., vol. 24, no. 6, pp.1654-1665, Jun. (2009).

DOI: 10.1109/tpel.2009.2016098

[10] H. Fujitha A resonant gate drive circuit capable of high frequency and high efficiency operation, IEEE Trans. Power Electron, Vol . 25, no. 4 pg. 962-909. Apr (2010).

DOI: 10.1109/tpel.2009.2030201

[11] P. Preethi and R. Mahalakshmi Implementation of zero current switching in step up/step down resonant converter", "International journal of engineering science and technology(IJEST), Vol. 3, No. 2, Feb (2011).

[12] Farzam Nejabatkhah, Saeed Danyali, Seyad Hossein Hosseini, Mehran Sabahi and Seyedabdolkhalegh Mozaffari Modeling and Control of a New Three-Input DC-DC Boost Converter for Hybrid PV/FC/Battery Power Systems, IEEE Trans on Power Electronics, Vol. 27, No. 5, May, (2012).

DOI: 10.1109/tpel.2011.2172465
