The Amorphous/Crystalline Silicon Interface Research of HIT Solar Cells by Simulation

Abstract:

In this paper, we have focused on the influence of interface state density and band offsets on the performance of HIT solar cells by simulation. The interface state density D_it have negative influence on the open-circuit voltage V_OC, fill factor FF and the short circuit current J_SC, beyond different D_it respectively. V_OC decreases monotonically with increasing D_it only when D_it is greater than 10¹⁰ cm^-2, and for FF and J_SC D_it is 10¹² cm^-2, 10¹³ cm^-2, respectively. Observed reduction in V_OC (D_it is from 1×10¹⁰ cm^-2 to 5×10¹³ cm^-2) may be due to the enhanced recombination possibility, which diminishes the difference in quasi Fermi energies from 0.8 eV to 0.46 eV. Reduction of J_SC (D_it is from 1×10¹³ cm^-2 to 5×10¹³ cm^-2) is connected with the carrier recombination rate that is heightened from 2.43×10²⁴cm^-3/s to 3.1×10²⁶cm^-3/s, which is markedly by two orders of magnitude. In addition, our research results demonstrate that by increasing the conduction band offset E_C (from 0.09eV to 0.15 eV), the V_OC could be increased by 15.9 mV, while the performance of HIT solar cells is not affected by the valence band offset E_V. The increase of E_C results in the rising of V_bi and thus improves V_OC. It is worth mention that, the recombination potential V_Re could be decreased from 232 meV to 208 meV by the increase of E_C (from 0.09eV to 0.15eV) and thus is favorable to V_OC. Consequently, when the interface state density is less than 10¹⁰ cm^-2 and the conduction band offset reaches 0.15eV, we can optimize the performance of HIT solar cells to achieve 24.95% efficiency.

• Periodical: Advanced Materials Research (Volume 773)
• Pages: 124-131
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.773.124
• Online since: September 2013
• Authors: Hao Li, Xiang Bo Zeng, Xiao Bing Xie, Ping Yang, Jing Yan Li, Xiao Dong Zhang, Qi Ming Wang
• Keywords: Band Offsets, Hit, Interface State Density

References

[1] Atsuhiko Fukuyama , Daisuke Ishibashi , Yohei Sato, et al, Journal of Non-Crystalline Solids, Vol. 358 (2012), pp.2206-2208.

[2] A. Luque, S. Hegedus, Handbook of Photovoltaic Science and Engineering, 2nd ed., Wiley, New York, (2011).

[3] A. Descoeudres, L. Barraud, Stefaan De Wolf, et al, APPLIED PHYSICS LETTERS, Vol. 99 (2011), pp.123506-3.

[4] Stefaan De Wolf, Sara Olibet, and Christophe Ballif, Appl. Phys. Lett. Vol. 93 (2008), pp.032101-3.

[5] Stefaan De Wolf and Michio Kondo, J. Appl. Phys. Vol. 105 (2009), pp.103707-1–103707-6.

[6] L. Zhao, C.L. Zhou, H.L. Li, et al, Solar Energy Materials & Solar Cells Vol. 92 (2008), pp.673-681.

[7] Antara Datta, J. Damon-Lacoste, P. Roca i Cabarrocas , P. Chatterjee, Solar Energy Materials & Solar Cells, Vol. 92 (2008), pp.1500-1507.

DOI: 10.1016/j.solmat.2008.06.015

[8] Vinh Ai Dao, Jongkyu Heo, Hyungwook Choi, et al, Solar Energy, Vol. 84 (2010), pp.777-783.

[9] Wang Jianqiang, Gao Hua, Zhang Jian, et al, Journal of Semiconductors, Vol. 33(3), (2012).

[10] N. Jensen, R.M. Hausner, R.B. Berman, J.H. Werner, U. Rau, Prog. Photovolt. Res. Vol. 10 (2002), pp.1-13.

[11] T.H. Wang, M.R. Page, E. Iwaniczko, D.H. Levi, Y. Yan, H.M. Branz, and Q. Wang, the 14th Workshop on Crystalline Silicon Solar Cells and Modules，200408, pp.1-8.

[12] Hidenori M, Yoshinori H. Appl Phys Lett, Vol. 50 (1987), p.326.

[13] Lequeux N, Cuniot M. J Non-Cryst Solids, Vol. 114(2), p.555, (1989).

[14] M.C. Delfina, Dr. Thesis. Department d'Enginyeria ElectrÒnica, Universitat Politècnica De Catalunya. Available from: <http: /www. tdr. cesca. es/TESIS_UPC/AVAILABLE/ TDX-1106108-132529/01Dmc01de01. pdf>, (2008).

[15] S. M. Sze, Kwok K. Ng, Physics of Semiconductor Devices (Third Edition), John Wiley & Sons, Hoboken, New Jersey, (2007).
