Software System Development of Crane Structural Health Monitoring

Abstract:

In order to improve the level of safety technology and safeguard work efficiency, software is developed. The software is divided into several functional modules: User information Management Module, System Settings Module, Information Collection and Transmission Module, Database Management Module, Data Analysis Module, Site Display Module and User Help Module. This paper focuses on the development and application of the system software. Sensors data is collecting by a FBG System, and directly send into Crane Structure Health Monitoring and Security Alarm Expert System via data filtering and data correction procedures. Users can access the expert systems data network and expert system can send warning or alarm information to user via Wi-Fi. Its the main part of the software platform. After software functional use cases,the next thing to do is the dynamic behavior of software modeling. The dynamic behavior is related to information exchange between users and software, software and peripherals.

• Periodical: Advanced Materials Research (Volumes 774-776)
• Pages: 1599-1603
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.774-776.1599
• Online since: September 2013
• Authors: Guojian Huang, Dong Hui Wang, Xin Hua Wang, Zhen Yu He
• Keywords: Crane, Expert System, Structural Health Monitoring (SHM)

References

[1] Chen Feng. Research on Distributional Integrated Software System for Structure Health Monitoring[D]. Nanjing University of Aeronautics and Astronautics, (2006).

[2] Hasan Z, Hasweh F, Al-Nadi O A, et al. An automated structural health monitoring system[Z]. Denver, CO, United states: 2011991-1001.

[3] Srivastava A N, Schumann J. The Case for Software Health Management[C]. (2011).

[4] Flynn E B, Kpotufe S, Harvey D, et al. SHMTools: A new embeddable software package for SHM applications[Z]. San Diego, CA, United states: (2010).

DOI: 10.1117/12.848234

[5] Taylor S G, Carroll J, Farinholt K M, et al. Embedded processing for SHM with integrated software control of a wireless impedance device[Z]. San Diego, CA, United states: (2011).

DOI: 10.1117/12.881976

[6] Dubey A, Karsai G, Mahadevan N. Model-based software health management for real-time systems[C]. (2011).

DOI: 10.1109/aero.2011.5747559

[7] Ahlendorf H, Ag Z. Hardware / software design challenges of low-power sensor nodes for condition monitoring[J]. Design, Automation & Test in Europe Conference & Exhibition (DATE). 2010: 659.

DOI: 10.1109/date.2010.5457122

[8] GZSEI. Crane structural health monitoring system server software[P]. 2012. 2012SR113667.

[9] GZSEI. Crane Structural health monitoring system software V1. 0[P]. 2012. 2012SR113625.

[10] GZSEI. Crane structural health monitoring system touch screen HMI software V1. 0[P]. 2012. 2012SR113670.
