Strength Properties of Chestnut Structural Timber with Wane

Abstract:

Grading of timber for structural purposes allows material with similar physical and mechanical properties to be grouped together. The groups are defined by specific strength values and indicate the basic working stresses and stiffnesses to be used for structural design purposes. In particular, visual strength grading bases the assignment of each timber element to a grade on the characteristics that are visually measurable (i.e. knots, slope of grain, annual ring width). Very similar principles are implemented for the in situ assessment of timber structures, as recommended for example by the Italian standard UNI 11119, that specifies the procedures for the diagnosis of timber members. Currently, however, European standards and most of the national standards on strength grading refer to timber elements with rectangular cross section, while in existing buildings, members with irregular cross section are extremely common. Thus, 10 different provenances (5 from Italy and 5 from France) of chestnut timber were sampled. More than 600 structural elements with wane were visually examined in laboratory and all the characteristics were collected. Bending tests were then performed on each timber element until failure, and bending strength, as well as modulus of elasticity and density, were determined. Here, the limitations for the main strength-reducing characteristics and the characteristic values (fifth percentile for bending strength and density and the mean value for modulus of elasticity) of chestnut timber with wane are presented.

• Periodical: Advanced Materials Research (Volume 778)
• Pages: 377-384
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.778.377
• Online since: September 2013
• Authors: Michele Brunetti, Michela Nocetti, Paolo Burato
• Keywords: Castanea sativa, Irregular Section, Strength Class, Visual Strength Grading

References

[1] UNI 11119, Cultural heritage – Wooden artefacts – Load-bearing structures – On site inspection for the diagnosis of timber members. UNI Ente Nazionale Italiano di Unificazione, Milano, (2004).

[2] UNI 11035-3, Visual strength grading for structural timbers. Part 3: Timber Uso Fiume and Uso Trieste. UNI Ente Nazionale Italiano di Unificazione, Milano, (2010).

[3] M. Romagnoli, M. Nocetti, M. Sarlatto, L. Evangelistella, Dendrochronological assessment of chestnut (Castanea sativa Mill. ) for dating purposes in central italy, Dendrochronologia, 21 (2004) 117-130.

DOI: 10.1078/1125.7865.00048

[4] J.W.G. van de Kuilen, G.J.P. Ravenshorst, M. Brunetti, A. Crivellaro, Species independent strength grading of hardwoods, in: Proceedings of the International Scientific Conference on Hardwood Processing, Quebec City, Canada, 2007, pp.165-170.

[5] M. Nocetti, M. Bacher, M. Brunetti, A. Crivellaro, J.W.G. van de Kuilen, Machine grading of Italian structural timber: preliminary results on different wood species, in: Proceeding of the World Conference on Timber Engineering, Riva del Garda, Trento, Italy, (2010).

[6] A. Vega, M. Guaita, A. Dieste, J. Majada, I. Fernández, V. Baño, Evaluation of the influence of visual parameters on wave transmission velocity in sawn chestnut timber, in: Proceeding of the 17th International Nondestructive Testing and Evaluation of Wood Symposium, Sopron, Hungary, 2011, pp.311-317.

[7] A. Vega, A. Dieste, M. Guaita, J. Majada, V. Baño, Modelling of the mechanical properties of Castanea sativa Mill. structural timber by a combination of non-destructive variables and visual grading parameters, Eur. J. Wood Prod., 70 (2012).

DOI: 10.1007/s00107-012-0626-7

[8] R. Zanuttini, G. Boetto, M. Lauriola, N. Macchioni, L'indagine diagnostica sullo stato di conservazione della struttura portante, in :G. Belardi (Ed. ), Palazzo Corsini alla Lungara. Analisi di un restauro, Editrice l'Artistica di Savigliano, 2001, pp.161-176.

[9] N. Macchioni, M. Bernabei, M. Brunetti, C. Pollini, D. Calicchio, A. Crivellaro, Structural diagnosis on ancient timber structures: the example of the Diplomatic Room at the Royal Palace in Naples, In: Proceedings of the International Conference on Structural Health Assessment of Timber Structures, Lisbon, Portugal, 2011, pp.1-13.

[10] UNI 11035-1, Visual strength grading for structural timbers. Part 1: Terminology and measurement of features. UNI Ente Nazionale Italiano di Unificazione, Milano, (2010).

[11] UNI 11035-2, Visual strength grading for structural timbers. Part 2: Visual strength grading rules and characteristics values for structural timber population. UNI Ente Nazionale Italiano di Unificazione, Milano, (2010).

DOI: 10.3403/00560945

[12] EN 408, Timber structures - Structural timber and glued laminated timber - Determination of some physical and mechanical properties. CEN European Committee for Standardization, Brussels, (2012).

DOI: 10.3403/30159970

[13] EN 13183-1, Moisture content of a piece of sawn timber. Determination by oven dry method. CEN European Committee for Standardization, Brussels, (2003).

DOI: 10.3403/02558468

[14] EN 384, Structural timber – Determination of characteristic values of mechanical properties and density. CEN European Committee for Standardization, Brussels, (2010).

[15] EN 338, Structural timber – Strength classes. CEN European Committee for Standardization, Brussels, (2009).
