Study and Analysis of XIV Century Timber Built-Up Beams in Verona

Abstract:

Starting from XIV century, a very interesting construction technique was developed in Northern Italy for heavy-loaded or long-span beams: these special timber beams are composed by an assemblage of multiple parts that behave practically as they were made by a single piece, thanks to a clever system of indentations, obtaining in this way the overall dimensions of slender thin-walled and high-section that could not be fit by cutting a single log. The first witness of this system can be found in L.B. Alberti treatise and some detailed drawings in Leonardo da Vinci's codes, but some examples of these beams can still be found in exercise, like those we discovered in an ancient palace in Verona, dating from XIV century. The study of the mechanical behavior of these beams is presented, taking into account the orthotropic properties of the wood, as well as some comparison with other beams found in Ferrara, together with the discussion of some proposal for their reinforcement in order to assure a safe reuse of the historic building. A sort of pre-stress can be depicted in Leonardo's drawings, in order to assure the connection of different pieces and the efficiency of the framework.

• Periodical: Advanced Materials Research (Volume 778)
• Pages: 511-516
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.778.511
• Online since: September 2013
• Authors: Giulio Mirabella-Roberti, Michele Bondanelli
• Keywords: Historical Technique, Pre-Stress, Timber Composite Beam

References

[1] Seminar on Composed beams in Europe between middle age and modern times,. Mantua, Italy, June 20-22, 2012. Politecnico di Milano.

[2] L.B. Alberti.

[1485] L'Architettura (de re aedificatoria), G. Orlandi ed., Milan (1966).

[3] L. da Vinci, Il codice Atlantico della biblioteca Ambrosiana di Milano, critical transcription by A. Marinoni, Florence, (2000).

[4] E. Giunchi, R. Malvezzi, M. Russo, Travi composte in legno nella Ferrara rinascimentale. MSc Thesis, supervisors: C. Alessandri, R. Fabbri, in Ferrara Architettura Arte di costruire, vol 2, Ferrara (2004).

[5] S. Dandria, Commercio del legname da opera" nella valle dell, Adige fra XIII e XVII secolo: assortimenti e impieghi in relazione alla diffusione delle travi composte, PhD Thesis, Politecnico di Milano, (2010).

[6] G.A. Breymann, Constructionen in Holtz, in Allgemeine Bau-Constructions-Lehre, Stuttgart, 1860, vol. 2.

[7] R. Von Mises, Mechanik der plastischern Formarderung von Kristallern. Angewandte Mathematik und Mechanik. 8 (1928), 161-185.

DOI: 10.1002/zamm.19280080302

[8] J.M. Cabrero, K.G. Gebremedhin, Evaluation of Failure Criteria in Wood Members, Proc. of 11th World Conference on Timber Engineering (WCTE 2010), 20-24 June 2010, Riva del Garda, Italy.

[9] M. Piazza, Behavior and rehabilitation of traditional timber structures. Proceedings of the International Conference on Protection of Historical Buildings (PROHITECH 09), Leiden: CRC Press, 2009, pp.75-83.
