Contact Stress Analysis and Optimization Design of Ball Cage Patterned Constant Speed Universal Joint

Abstract:

This paper takes ball cage patterned constant speed universal joint of as the research object. Using the 3 d modeling software solidworks to establish solid model and simplified it . Based on ANSYS, do finite element contact stress analysis by the universal joint of the two kinds of condition. find out the weak part,through the improvement of raceway design parameters, Relieve the stress concentration phenomenon, reduces the maximum stress, increases the service life of universal joint.

• Periodical: Advanced Materials Research (Volumes 785-786)
• Pages: 1172-1175
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.785-786.1172
• Online since: September 2013
• Authors: Yun Guang Cai, Yan Li, Yao Chen Shi
• Keywords: Ball Cage Patterned Constant Speed Universal Joint, Optimization Design, Stress Analysis

References

[1] Tang Shuang-qing, Hu Huan , Fan Ji-hong. Raceway contact stress analysis of ball-cage type constant velocity joint. Mechanical design and manufacturing. 2011(3): 49~51, In Chinese.

[2] Chen Jing. Structural Strength Analysis of Constant Velocity Joints for Car Drive-shaft by Finite Element Method : [Master Thesis]. Chang Chun: Vehicle Engineering , Jilin University, 2005, 08.

[3] Yuan Feng Yang. Structural Strength Finite Element Analysis of Automotive Constant Velocity Drive-shaft: [Master Thesis]. Chang Chun: Vehicle Engineering , Jilin University, 2004, 05.

[4] Tang Shuang-qing, Hu Huan, Xu Yan-fei . Analysis on Influencing Factors ofContact Stress on Raceway of Rzeppa Constant Velocity Universal Joint: Bearings, 2010(3): 8~12, In Chinese.
