Numerical Modeling of Ship Composite-Based on Aluminum Casting as Alternative Materials for Ship Building

Abstract:

The structure and construction of the ship is made of aluminum alloy, generally are of wrought aluminum alloys, when experiencing fatigue failure caused by a cracked vessel structure, is a serious problem. Reviewing of 'weakness' of wrought aluminum alloys for the ship, then in this study tries to provide material alternative for ship building is composite material based on aluminum casting AlSi10Mg (b) and reinforcing material silicon carbide (SiC), which has been in-treatment with the optimum composition 15%. Analysis of numerical computation with the help of ANSYS software version 2.00 to be made numerical modeling ship to ship aluminum EN AC-AlSi10Mg (b) and ship composite EN AC-AlSi10Mg (b)+SiC*/ 15p whether the material can be applied to building ship for see the distribution of stress . The results of the stress distribution in both of model numerical of ship, its value does not exceed the stress permits (sigma 0.2) and have a factor of safety above the minimum allowable limit, so it is safe to use. The overall, in numerical modeling, the ship material aluminum and ship composite materials can be used as an alternative material for ship building, however is still needed comprehensive testing in the field.Keywords: Aluminum casting ; ship building ; composite EN AC-43100(AlSi10Mg (b))+SiC*/15p; ANSYS ver.12,0

• Periodical: Advanced Materials Research (Volume 789)
• Pages: 143-150
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.789.143
• Online since: September 2013
• Authors: Prantasi Harmi Tjahjanti, Prantasi Harmi Tjahjanti, Eko Panunggal, Darminto Darminto, Wibowo Harso Nugroho
• Keywords: Aluminum Cast, ANSYS Ver.12,0, Composite EN AC-43100(AlSi10Mg(b))+SiC /15p, Ship Building

References

[1] Zhou zhao, Song Zhijian and Xu Yingkum, 1991, Effect of Microstructure on the Mechanical Properties of an Al Alloy 6061 , J. material science and engineering, A132, p.83.

DOI: 10.1016/0921-5093(91)90364-s

[2] Pearce PJ, Grabovac I, 1994, Composite Reinforcement of Ship Superstructures, Naval Platform Technology Seminar Singapore, December.

[3] Sielski. RA, Taylor P, 2008, Predicting the Failure of Aluminum Exposed to Simulated Fire and Mechanical Loading Using Finite Element Model, Journal of Offshore and Arcric Engineering, 3(1), pp.57-65.

[4] Huang Scott Xiaodi and Paxton Kip, 1998, A Macrocomposite Al Brake Rotor for Reduced Weight and Improved Performance, Journal of Materials, Innovations in Aluminum, Part IV, August (1998).

DOI: 10.1007/s11837-998-0453-9

[5] Tzimas E., Zavaliangos A.: Acta Mater 47 (1999) 517 – 528.

[6] Thomas, W. M. 1991 Friction Stir Butt Welding U.S. Patent No. 5, 460, 317.

[7] Tjahjanti P. H, Darminto, Eko P, Nugroho W. H, 2007, Kaji. Awal PembuatanMaterial Struktur Kapal Dari Bahan Komposit Berbasis Aluminium Dengan Metode Pengecoran , Prosiding Seminar Nasional Pascasarjana VII-2007 Program Pascasarjana Institut Teknologi Sepuluh Nopember (ITS) Surabaya Volume II ISBN: 979-545-0270-1.

DOI: 10.32315/sem.4.088

[8] Tjahjanti P. H, Darminto, Panunggal Eko, Nugroho W. H, 2007, Perlakuan Khusus Cara Pencampuran Bahan Penguat Silikon Karbida Dan Matrik Aluminium/Aluminium Alloy Pada Bahan Aluminium Metal Matrix Cast Composite, Prosiding Seminar Nasional Teknoin, Jurusan Teknik Mesin F. Teknik Industri Univ. Islam Indonesia (UII) Jogjakarta, ISBN: 978-979- 96964-5-8, ISSN: 0583-8697.

DOI: 10.30596/rmme.v3i2.5273

[9] Tjahjanti P. H, Darminto, Panunggal Eko, Nugroho W. H, 2012, Sifat Mampu Las Material Komposit EN AC-43100 (AlSi10Mg(b)+SiC*/15p Dilihat dari Hasil Uji Mekaniknya, Jurnal Teknik Mesin Institut Teknologi Sepuluh Nopember (ITS) ISSN 1411-9471 Volume 12, nomor 1 Januari 2012 Halaman: 38-45.

[10] BKI (2009). Rules for the Classification and Construction of Seagoing Ships Vol II. Biro Klasifikasi Indonesia. Jakarta.

[11] Taggart, 1980, Ship Design and Construction, SNAME.
