Research on Tractor of Coal Mine Horizontal Belt Extension Transfer Machine

Abstract:

Coal mine horizontal belt extension transfer machine is designed in order to solve the mine loading efficiency is not high; especially the most loading mechanical failed to solve continuous loading problem. This machine can also load a whole column tramcars and tramcars without modification with direct use, efficiency improve obviously. This paper first introduces transfer machine structure and working process, and introduces its important part tractor, structure and main function; Then as the main force of tractor parts, we frame for stress analysis, and set up the frame of 3-D model; Finally put the model into ANSYS of its structure statics analysis, and according to the result of analysis frame structure optimization. We will use the same approach to the design of tractor other components, finally complete the complete tractor. Through the study of tractor, summarizes the design methods for other similar mechanical similar provide a theory basis for the design.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 750-753
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.750
• Online since: September 2013
• Authors: Ping Huai Mao, Bing Zhai, Jing Xi Li
• Keywords: Coal Mine Transfer Machine, Continuous Loading, Frame, Structure Design, Tractor

References

[1] P.H. Mao, Q. Ye, Y.M. Bian, Y.M. Xia and Y.L. Mao: Chinese. Patent CN 102295166 A. (2011).

[2] P.H. Mao, Q. Ye, Y.M. Bian, Y.M. Xia and Y.L. Mao: Chinese. Patent CN 102191948 A. (2011).

[3] P.H. Mao, J.X. Li: 2012 International Conference on Manufacturing Engineering and Automation (Guangzhou, China, November 16-18, 2012). Vols. 591-593, P. 80-83.

[4] P.H. Mao, J.X. Li: 2012 International Conference on Manufacturing Engineering and Automation (Guangzhou, China, November 16-18, 2012). Vols. 591-593, P. 44-47.

[5] P.H. Mao, J.X. Li: 2012 International Conference on Manufacturing Engineering and Automation (Guangzhou, China, November 16-18, 2012). Vols. 591-593, P. 789-792.

[6] P.H. Mao, J.X. Li: 2012 International Conference on Manufacturing Engineering and Automation (Guangzhou, China, November 16-18, 2012). Vols. 591-593, P. 464-467.

[7] X.X. Chen, J.Z. Xing and Y.K. Wang: ANSYS Analysis Examples and Engineering Application (Machinery industry press, China, 2004), P. 45-55 (In Chinese).

[8] C.H. Zhang: ANSYS12. 0 structure analysis examples of engineering application analysis (Machinery industry press, China, 2010), P. 136-143. (In Chinese).
