Study on Dual-Plane Ball Polishing Method for Finishing Ceramics Ball

Abstract:

This paper represents a dual-plane polishing method for ceramics ball. Compared with traditional ball polishing method, its upper and lower plate are all flat and easy to use soft pad to polish, so it can largely reduce the surface mechanical damage and obtain high quality processing surface. This paper analyzes surface polishing trajectory by calculation and simulation to test the polishing trajectory uniformity. A mathematics model of polishing process is established to disintegrate the process of a balls movement. Experiment is operated in dual-plane planetary polishing machine. The result shows that perfect polishing surface and spherical error can be obtained under the proper process parameters, the surface roughness achieves 4nm and the spherical error can reach 0.217μm.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 444-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.444
• Online since: September 2013
• Authors: Kai Ping Feng, Zhao Zhong Zhou, Bing Hai Lv, Ju Long Yuan
• Keywords: Ceramics Ball, Dual-Plane Polishing, Polishing Trajectory

References

[1] Dong-Woo Kim J-W L, Myeong-Woo Cho, Young-Jae Shin, Jingwen Xu, Ki-Ju Lee. Ultra precision polishing of Si3N4 ceramics using magnetorheological fluids and diamond abrasives [J]. Journal of Ceramic Processing Research. 2009, Vol. 10, No3 : 290-295.

[2] Lu Feng, Wu Hou, Zhang Ke. Technological investigation on taper grinding for hybrid bearing ceramic ball [J]. Journal of Northeastern University(Natural Science), 2004, 25(1): 82-85.

[3] Yang Tiebin, Wang Liqin, Gu Le, Zheng Dezhi. Surface defects analysis of Si3N4 bearing balls in lapping process [J]. Lubrication engineering, 2006, No7: 45-47.

DOI: 10.1109/wcica.2006.1713625

[4] LEVESQUE G, ARAKERE N K. An investigation of partial cone cracks in silicon nitride balls [J]. International Journal of Solids and Structures, 2008, 45(25-26): 6301-6315.

DOI: 10.1016/j.ijsolstr.2008.07.031
