Finite Element Simulation of Minimum Uncut Chip Thickness in Micro Mill-Grinding Ti6Al4V Based on Single-Edge Single-Grit Model

Abstract:

The cutting edge radius R_e leads to the minimum uncut chip thickness in micro machining. The single-edge single-grit model was developed for micro mill-grinding in this paper. Simulations for Ti6Al4V were performed in various cutting depths, and the minimum uncut chip thickness of micro mill-grinding was confirmed to be between 0.25R_e and 0.3R_e (approximate 0.275R_e). Various grain heights of protrusion were investigated to discuss the influence of grain depths of cut on the minimum uncut chip thickness. The minimum uncut chip thickness will increase if the grinding debris forms, while it will get smaller if the grinding debris cant be generated.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 622-627
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.622
• Online since: September 2013
• Authors: Ya Dong Gong, Chao Wang, Guo Qiang Yin, Hao Xu, Xue Long Wen
• Keywords: Finite Element, Micro Mill-Grinding, Minimum Uncut Chip Thickness, Single-Edge Single-Grit Model

References

[1] Z.J. Yuan, M. Zhou and S. Dong. Effect of Diamond Tool Sharpness on Minimum Cutting Thickness and Cutting Surface Integrity in Ultraprecision Machining. Journal of Materials Processing Technology, Vol. 62 (1996), pp.327-330.

DOI: 10.1016/s0924-0136(96)02429-6

[2] S.M. Son, H.S. Lim and J.H. Ahn. Effects of the Friction Coefficient on the Minimum Cutting Thickness in Micro Cutting. International Journal of Machine Tools & Manufacture, 2005, Vol. 45, pp.529-535.

DOI: 10.1016/j.ijmachtools.2004.09.001

[3] S. Venkataehalam, S.Y. Liang. Effects of ploughing forces and friction coefficient in micro scale machining. Transactions of the ASME, Vol. 129 (2007), pp.274-280.

[4] Z.Y. Shi. Study on Micro cutting Mechanism Minimum Uncut Chip Thickness. (Shandong University, Ji'nan 2011).

[5] J.H. Wu, Z.Y. Shi. Minimum Chip Thickness in Orthogonal Micro-cutting Based on Plasticity Strain Gradient Theory. China Mechanical Engineering, Vol. 20, No. 18, (2009), pp.2227-2230.

[6] S. Subbiah. Some Investigations of Scaling Effects in Micro-cutting. (Georgia Institute of Technology, Atlanta 2006).

[7] M. Malekian, M.G. Mostofa, S.S. Park, et al. Modeling of minimum uncut chip thickness in micro machining of aluminum. Journal of Materials Processing Technology, Vol. 212 (2012), pp.553-559.

DOI: 10.1016/j.jmatprotec.2011.05.022

[8] X.M. Lai, H.T. Li, C.F. Li, et al. Modeling and analysis of micro scale milling considering size effect, micro cutter edge radius and minimum chip thickness. International Journal of Machine Tools & Manufacture, Vol. 48 (2008), pp.1-14.

DOI: 10.1016/j.ijmachtools.2007.08.011

[9] M.R. Vaziri, M. Salimi, M. Mashayekhi. Evaluation of chip formation simulation models for material separation in the presence of damage models.

DOI: 10.1016/j.simpat.2010.09.006

[10] C.Z. Duan, T. Dou, Y.J. Cai , Y.Y. Li. Finite Element Simulation and Experiment of Chip Formation Process during High Speed Machining of AISI 1045 Hardened Steel. International Journal of Recent Trends in Engineering, Vol 1, No. 5, (2009).

DOI: 10.1109/iccet.2010.5486196
