The Dynamic Analysis of Micro-Scale Edge in the Process of Micromilling

Abstract:

The micro-processing technology has gradually become a hot topic problem, especially in micro-scale milling chatter prevention with the development of the information age. In allusion to the actual case of micro-milling, the dynamic theoretical research is analyzed in-depth about the Fourier method and the average tooth angle method. Compared to two ways, the former is close to the actual processing requirements. The lobes are obtained use the two ways. Micro milling parameters are selected in the stable area and unstable region. Stable and non-stable curve and surface quality of machined parts are obtained after micro-milling test. The chatter points, non-chatter point and uncertain point are obtained in the high spindle speed, which are consistent with theoretical analysis. In contrast, the distribution of chatter points in the low-speed spindle speed. The reason is that the damping effect is produced in the micro-scale milling process. The research of micro-scale milling chatter, which has a certain significance to improve parts of precision machined parts, reduce the wear and tear of the micro-milling blade and extend micro-tool life.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 628-637
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.628
• Online since: September 2013
• Authors: Ya Dong Gong, Jin Feng Zhang, Jun Cheng, Xue Long Wen, Chao Wang, Guo Qiang Yin
• Keywords: Axial Cutting Depth, Damping Effect, Lobe Diagram, Micro Chatter, Spindle Speed

References

[1] Tony L. Schmitz, K. Scott Smith. Machining dynamic-frequency response to improved productivity [M]. New York: Springer, (2009).

[2] Kai Cheng. Machining dynamics-fundamentals applications and practices [M]. New York: Sprnger, (2006).

[3] Robert I. King. Handbook of high-speed machining technology[M]. New York: Chapman and Hall. (1985).

[4] Yinuo Shi, Frederik Mahr, Utz von Wagner, Eckart Uhlmann. Chatter frequencies of micromilling processes: influences factors and online detection via piezoactuators [J]. International Journal of Machine Tools and Manufacture, 2012, Vol. 56(6): 10-16.

DOI: 10.1016/j.ijmachtools.2011.12.001

[5] A. Baschin, P. Kahnis,D. Biermann. Dynamic analysis of the micromilling process influence of tool vibration on the quality of microstructures[J]. Mat. -wiss. u. Werkstofftech, 2008, Vol. 39 (9): 616-621.

DOI: 10.1002/mawe.200800334

[6] Guillem Quintana, Joaquim Ciurana. Chatter in machining Processes: A review [J]. International Journal of Machine Tools and Manufacture, 2011, Vol. 51(7): 363-376.

DOI: 10.1016/j.ijmachtools.2011.01.001

[7] Martin B. G. Jun, Xinyu Liu, Richard E. Devor, Shiv G. Kapoor. Investigation of the dynamics of microend milling-PartⅠ: Model development[J]. Journal of Manufacturing Science and Engineering, 2006, Vol. 128 (11): 893-900.

DOI: 10.1115/1.2193546

[8] Martin B. G. Jun, Richard E. Devor, Shiv G. Kapoor. Investigation of the dynamics of microend milling- PartⅡ: Model validation and interpretation[J]. Journal of Manufacturing Science and Engineering, 2006, Vol. 128(11): 901-912.

DOI: 10.1115/1.2335854

[9] H. Z. Li, X. P. Li X. Q. Chen. A novel chatter stability criterion for the modelling and simulation of the dynamic milling process in the time domain[J]. International Journal of Advanced Manufacturing Technology, 2003, Vol. 22(7): 619-625.

DOI: 10.1007/s00170-003-1562-9
